Manual
VS2 KL
Content
1 x Torx (TX15)
offset screwdriver
1 x pleated blind
1 x cleaning cloth
Preparing the window
Degrease the window and glass with the provided wipes*.
1
Let the surface dry during 5 minutes after degreasing it.
www.diaz.be
2 x operating
handle
4 x Adapter (2x left/ 2x right)
2x
adhesive
profiles
1
