DF comfort 20
Content
side channel
DIN 7981 Ø3,9
x 16 mm for
wooden and
synthetic
windows
Mounting of the pleated blind
1
Place the side channels so that the distance is the same at the top
and at the bottom. Fix the channels in the window frame.
www.diaz.be
pleated blind
2 x handles
The older window model
GGU with 105° mortise
requires the spacers
supplied to be inserted into
the running rail. Place the
spacers near the screw.
