Manual
Roller blind easy
Description of the parts
Installation of the brackets
First draw the place of the brackets onto the ceiling or wall. Make sure the brackets
1
are placed at the exact finished width of the roller blind.
Screw the brackets to the ceiling or wall.
2
Always make sure that the brackets are
installed in one straight line.
Installation of the blind onto the brackets
Slide the plastic covers over the screws of the metal brackets (figure 1).
1
Now hook the roller blind over the edge of the bracket on the operation side (figure 2).
2
Push the spiral spring on the non operation side (figure 3).
3
Position the roller blind between the brackets till the blind clicks in the hole of the bracket.
4
figure 1
www.diaz.be
1
2
3
4
1. Plastic end caps
2. Brackets
3. Operation side
4. Operation chain
5. Hem bar
5
figure 2
figure 3
1
Advertisement
Table of Contents
Related Manuals for Diaz 3854
Summary of Contents for Diaz 3854
- Page 1 Now hook the roller blind over the edge of the bracket on the operation side (figure 2). Push the spiral spring on the non operation side (figure 3). Position the roller blind between the brackets till the blind clicks in the hole of the bracket. figure 1 figure 2 figure 3 www.diaz.be...
- Page 2 Take down the roller blind Use a screw driver to push the spiral spring to the inside of the blind. (figure 4) Slide the roller blind out of the brackets. figure 4 www.diaz.be...
