Summary of Contents for HETRONIC ERGO 120

  • Page 1 USER’S MANUAL ERGO 120 USER OPERATION AND SERVICE MANUAL 08/2018 www.hetronic.com...
  • Page 2: Table Of Contents

    3.1 General Description ......................6 3.2 Ergo 120 Features ........................ 6 3.3 Ergo 120 Programming ......................6 3.4 Standard Ergo 120 2.4GHz Configuration ................6 4. Theory of Operation ......................... 12 4.1 Stop Function ........................12 5. Changing the battery ....................... 13 5.1 Recharging your Batteries ....................
  • Page 3: Safety

    Your radio remote control is designed for remote operation of machines and systems using safe wireless communications technology. Hetronic assumes no liability for damages resulting out of the non-observance of this operating manual. All persons, working with this radio remote control must ...
  • Page 4: Protective Features

    ERGO 120 can harm the unit or lessen its lifespan. Do not keep your ERGO 120 stored in a closed container for extended periods of time unless it is powered off. Charging the ERGO 120 in a closed container is a potential fire hazard and may shorten its lifespan.
  • Page 5: Introduction And Functional Description

    2. I ntroduction and Functional Description We congratulate you on the purchase of your new Hetronic ERGO 120 push button transmitter. You have chosen a high quality product. Familiarise yourself with the unit before using it for the first time. In addition please carefully refer to the operating instructions and the safety advise given in this manual.
  • Page 6: Your Ergo 120 Transmitter

    Ergo 120 configuration – Transmitter mode Section for more information. 3.4 Standard Ergo 120 2.4GHz Configuration 3.4.1 Transmitter version The Ergo 120 2.4GHz transmitter is factory programmed to one of the following configurations: A. Ergo 120 2.4GHz-V1  14 Single detent pushbutton...
  • Page 7: Figure 2. Ergo 120 Transmitter (Right, Front, Left)

    C. Ergo 120 2.4 GHz-Prop  2 Proportional pushbuttons  10 Single detent pushbuttons  1 Single detent START pushbutton Figure 2. Ergo 120 Transmitter (Right, Front, Left) 1-10 Up to 2 Detent Momentary Pushbutton (S1-S10) 11-15 Single Detent Momentary Pushbutton (S11-S15)
  • Page 8: Table 2. Analog Configuration Parameters

    Service mode. This feature can also be disabled by assigning the value as 0000. 3.4.4 Switches Your Ergo 120 transmitter can have 10 front and 4 side switches (for V1 and V2 type). These switches can be configured using the H-Link DK tab and each switch can be assigned with 3 different DK’s.
  • Page 9: Table 3. Radio Parameters

    Splash screen (logo) duration can be set from the ‘On time’ field in the Feedback tab on H- Link. 3. Time & Date Time displayed on the status bar of your Ergo 120 transmitter can only be in 24hrs format. This can be updated either through PC H-Link, User control tab or through service mode.
  • Page 10 ERGO 120 4. Received Signal Strength Indicator (RSSI) Received signal strength is displayed on status bar of your Ergo 120 transmitter and indicates the transmitter signal strength (If feedback is enabled then it shows the strength of the receiver signal).
  • Page 11 RS232 3.4.12 Belt Clip and Holster The practical belt clip allows the user to hang the Ergo 120 transmitter and continue operation hands free or store the transmitter hung vertically when not in use. The holster can be ordered as an add-on, with or without the belt, so as to protect the...
  • Page 12: Theory Of Operation

    4. T heory of Operation Your Ergo 120 transmitter works with a receiving device to transfer machine control commands via radio frequency to your machine. The transmitter electronically generates a carrier frequency that allows it to communicate with the receiver without the use of cables or wires.
  • Page 13: Changing The Battery

    5. C hanging the battery You may power your transmitter with a Hetronic rechargeable battery inserted into the back of the transmitter. Follow the instructions below to ensure best performance of your Ergo 120 transmitter and prolonged battery lifetime. 1. Confirm that your batteries are fully-charged. See “Recharging Your Batteries” section.
  • Page 14: Recharging Your Batteries

    If you have questions or problems operating your battery charger, please contact your dealer or Hetronic. Standard Hetronic rechargeable batteries are the Lithium polymer type. These batteries have no “memory effect” when charging a battery that is not fully discharged.
  • Page 15: Operating Your Transmitter

    6. O perating Your Transmitter 6.1 Holding Your Transmitter Hold the transmitter upright with the front facing you. Confirm that you are able to easily read and understand any operation text or symbols. Complete the following procedures once a day, before the start of an operation and at all shift changes.
  • Page 16: Stopping Radio Remote Control

    USER’S MANUAL | ERGO 120 Figure 1. Starting the Transmitter Figure 2. Stopping the Radio Remote Control 6.4 Stopping Radio Remote Control Press STOP. The word STOP appears and the transmitter sends an E-Stop telegram to the receiver for 2 seconds.
  • Page 17: Troubleshooting

    7. T roubleshooting If your Ergo 120 does not operate after normal start-up, follow the recommended troubleshooting sequence to help isolate the cause and determine corrective action. If you need more information, contact your dealer or Hetronic. PROBLEM PROBABLE CAUSE...
  • Page 18: Specifications

    USER’S MANUAL | ERGO 120 8. S pecifications Ergonomically designed Impact Resistant Polymer Housing Composite Environmental Protection IP 65 (Exceeds Nema 12/13) Weight ~480g (1.05lbs) including battery Height: 234 mm (7.3 in.) Dimensions Width: 107 mm (3.2 in.) Depth: 50 mm (1.3 in.)
  • Page 19: Warranty, Service, Repairs And Maintenance

    Work under guarantee/warranty must be carried out by Hetronic, or by an authorized service centre specified by Hetronic. Any modification, reconstruction or extension of the systems without a written agreement of Hetronic may lead to the loss of your warranty and guarantee claims. The following are not covered by the guarantee/warranty: ...
  • Page 20: Regulatory Information

    As a designer and manufacturer of electrical and electronic products covered by RoHS and RoHS2, Hetronic confirms that to the best of its knowledge at the date of this statement, none of the products supplied by it contain any of the hazardous substances in excess of permitted levels referred to in the Directive 2002/95/EC.
  • Page 21 These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 22 Hetronic reserves the right to discontinue, make changes to, and add improvements upon its products at any time without public notice or obligation. Hetronic disclaims liability for any claims or damages, whether regarding property, personal injury or death arising out of the use of...
