Smart Energy Plug PAN44
This plug-in ON/OFF switch PAN44 is a devices displaying the Z-Wave Plus
also be used security enabled wireless switch, based on Z-Wave Plus technology. Z-
Wave Plus
TM
enabled with it regardless of the manufacturer, and can also be used in
other manufacturer's Z-Wave
TM
enabled networks. Remote On/Off control of the con-
nected load is possible with another manufacturer's wireless Controller. Each switch is
designed to act as a repeater. Repeaters will re-transmit the RF signal to ensure that the
signal is received by its intended destination by routing the signal around obstacles and
radio dead spots. Because PAN44 supports Security Command Class, it can learn with
Secured controller. Its functionality and supported command classes are identical when
included as a secure and non-secure device.
This plug-in ON/OFF switch is able to detect instance wattage (3000W/230VAC/13A)
and overload current (14.5A with resistive load) of connected lights or appliances. When
detecting overload state, the Switch will be disabled and it's On/Off button will be lock-
out of which LED will flash quickly. However, unplug and reconnect the switch will re-
set its overload condition to normal status.
Specification
Operating Voltage
Maximum Load (Ampere)
Range
Operating Temperature
Frequency Range
RF Maximum Power
** Specifications are subject to change and improvement without notice.
Troubleshooting
TM
logo can
Symptom
The Switch not working
and LED off
The Switch LED illumi-
nating, but cannot control
the Switch of the load at-
tached
The Switch LED illumi-
nating, but the Detector
cannot control the Switch
LED keep flashing, but
cannot control
100V~240V / 50Hz~60Hz
13A (Resistive load) PAN44-1; PAN44-2; PAN44-3
Minimum 40 m in door 100m outdoor line of sight
0°C ~ 40°C
908.4MHz & 916.0MHz/ USA (PAN15-1);
922~927MHz/ Taiwan/ Japan (PAN15-2)
+5dBm
Cause of Failure
1.The Switch is not plugged into
1. Check power connections
the electrical outlet properly
2. Don't open up the Switch
2.The Switch break down
and send it for repair.
1. Set the ON/OFF switch of
1.Check if the load plugged into
the load attached to ON
the Switch has its own ON/OFF
2. Unprotected the switch or
switch
follow the instruction of pro-
2. The switch is protected
tection.
1. Not carry out association
1. Carry out association
2. Same frequency interference
2. Wait for a while to re-try
Overload occurs
Remove the load attached or
check max. load cannot ex-
ceed 13A (Resistive load)
Recommendation
Advertisement
Table of Contents
Related Manuals for Philio PAN44-1
Summary of Contents for Philio PAN44-1
- Page 1 Specification Smart Energy Plug PAN44 Operating Voltage 100V~240V / 50Hz~60Hz Maximum Load (Ampere) 13A (Resistive load) PAN44-1; PAN44-2; PAN44-3 Range Minimum 40 m in door 100m outdoor line of sight Operating Temperature 0°C ~ 40°C 908.4MHz & 916.0MHz/ USA (PAN15-1);...
-
Page 2: Auto Inclusion
auto inclusion. QRCODE Auto Inclusion The function of auto inclusion will be executed as long as the switch does not have Node ID and just plug the switch into a wall outlet. Note: Auto inclusion timeout is 2 minutes; during which the node information of explorer frame will be emitted once several seconds. -
Page 3: Led Indication
2. Pressing On/Off button three LED Indication times within 2 seconds will enter exclusion mode. To distinguish what mode the switch is in, view from the LED for identification. The color of LED could be blue、cyan、green、orange、pink or red, it represents the power consumption from 3.Node ID has been excluded. - Page 4 3. Press the button or switch on the load to the ON position. Upon receipt of the following commands from a Z-Wave Controller, the load 4. To manually turn ON the Switch, press and release the On/Off button. The attached to the Switch will turn on or off. LED will turn ON, and the load plugged into the Switch will also turn ON.
- Page 5 0x01，Precision = 1，Scale = 0x02，Size = 4，Meter Value(W) ] When the power consumption of load varies over 5%, it will send Meter report Example: to the nodes of Grouping 1. Meter Value 1 = 0x00 (W) Meter Value 2 = 0x00 (W) Meter Report Command: Meter Value 3 = 0x03 (W) [Command Class Meter ，...
- Page 6 2-2-4 AC load Voltage (V) Meter Value 1 = 0x01(I) When receiving Meter Get Command, it will report Meter Report Command to Meter Value 2 = 0x21(I) the node. AC load current = (Meter Value 1*256) +(Meter Value 2)= 2.89 (A) Meter Get Command: [Command Class Meter, Meter Get, Scale 2-2-6 load power factor (PF) =0x04(V)]...
- Page 7 cumulated Power Consumption (KWh) to Group1 node every 1 hour. The Threshold of 1300*0.01A maximum interval to report its Accumulated Power Consumption (KWh) is current for Load 10-1300 0.01A 1300 = 13A 227.55 days (10min*32767/1440=227.55 days). When the setting is 0, PAN44 caution will disable KWH auto report function.
- Page 8 3-8 Watt differential mode：The default setting is 1 (= 5%). Configuration Highest granted Security Class Whenever Watt value of PAN44 changes over 5% of last reading value, it will Device Reset Locally Highest granted Security Class send Meter report to the group 1 nodes. However, if Watt differential mode as Firmware Update Meta Highest granted Security Class 0, the unsolicited report will be disabled.
- Page 9 This transmitter must not be co-located or operating in conjunction with any other an- tenna or transmitter. Company of License Holder：Philio Technology Corporation Address of License Holder ：8F., No.653-2, Zhongzheng Rd., Xinzhuang Dist., New Taipei City 24257, Taiwan(R.O.C)
