Wall Cabinet
ASSEMBLY INSTRUCTIONS
These assembly instructions are only applicable for all Single/Double Ovenl Cabinets
OC3384SD OC3390SD
•Assembly is made fast and easy with
Threespine
®
click furniture technology.
•Patent Protected,
www.valinge.se/patents
•Produced under license
from Välinge Innovation.
Advertisement
Related Manuals for CABINETS TO GO Findley & Myers OC3384SD
Summary of Contents for CABINETS TO GO Findley & Myers OC3384SD
- Page 1 Wall Cabinet ASSEMBLY INSTRUCTIONS These assembly instructions are only applicable for all Single/Double Ovenl Cabinets OC3384SD OC3390SD •Assembly is made fast and easy with Threespine ® click furniture technology. •Patent Protected, www.valinge.se/patents •Produced under license from Välinge Innovation.
- Page 2 General Instructions: ► Thank you for purchasing a Cabinets To Go product. You are now the proud owner of a high quality product designed to face the test of daily use and guaranteeing your enjoyment for many years to come.
- Page 3 NOTE: If installing a double oven, you will want to perform this step first to prepare the frame. Using a saw, cut the frame as shown below to remove the un-needed rails. (NOTE:Lay Frame and doors on a flat smooth soft work surface to prevent damage). The assembled double oven cabinet will look like this with the large opening, and a single...
- Page 4 Instructions: ► Place the side panel (A) face down on a flat soft working surface to ensure that the face is not scratched or damaged. (Figure 1). Install the Back Panel: Insert the back panel (B) into the groove of the side panel (A) and click it into place.
- Page 5 Install the Toe Kick : Insert the Toe Kick (E) into the free hole of side panel (A) .(Figure 4) Figure 4 Install the side Panel: Insert the side panel (A) into the groove of the back panel (B), top, bottom (C) and Toe kich (E) .
- Page 6 Install the framel: Insert the frame (F) into the groove of the side panel (A), top, bottom (C) and center panel (D) . Press down until they click into place. (Figure 6) Figure 7 Asemble screw 1" into the back of center panel (D) for "Single" or "Double" (Figure 8) Single Double Figure 8...
- Page 7 Assemble the drawer (X3) Install the drawer front into grove of drawer Install the drawer bottom into drawer box back, bottom, click into place (Figure 2) click into place (Figure 1) Figure 2 Figure 1 Asemble screw 1" into drawer back with drawer Install the drawer side into drawer back, drawer side and drawer front with drawer side(Figure 5) box back and front, click into place (Figure 3)
- Page 8 Assemble the drawer runner inside of cabinet with 2 screws 9/15" (e) for each side Put plastic block into free hole in the back panel (B) .(Figure 8) Figure 8 Assemble 3D locking device with 3 srews 6/15", to move out the slide and put drawer to click into the hook of slide with the hole in back side of drawer back .
- Page 9 Figure 5 12. Assemble 4 hinges into two doors by screw driver and 8 screw 7/15" (Figure 6) Figure 10 13. Assemble door with hinges to lelf and right of cabinet frame by 4 screw 4/5" (Figure 7) •Assembly is made fast and easy with Threespine ®...
- Page 10 aintenance: ► M For daily cleaning, use a dry cloth and a soft liquid cleaner. Never use abrasive cleaner containing aceton, chlorine or strong bleach. Also, do not use tool as scrapers, metallic brushes, and other products which canscratch or tarnish surfaces. Under no circumstances should you use chrome cleaner on chrome-plated or brass trim, hinges, handles, sockets etc.
