NetDisk User Manual
6. Aggregation or Mirroring is completed.
Aggregation: The Aggregated NetDisk is indicated by the word Aggr Primary:
NetDisk1. The NetDisk from the NetDisk bound box becomes the Primary Net-
Disk and the NetDisk from the NetDisk available box becomes the Secondary
NetDisk. The capacity of the Secondary gets added to the Primary NetDisk.
Mirroring: The Mirrored NetDisk is indicated by the word Mirror Primary: NetDisk
1. The NetDisk from the NetDisk bound box becomes the Primary NetDisk and
the NetDisk from the NetDisk available box becomes the Secondary NetDisk.
The Primary NetDisk is Mirrored to the Secondary NetDisk.

8.4.3 Enable NetDisk

1. Click NetDisk Administrator Tool
Note: NetDisk 1 is disabled Primary NetDisk
and NetDisk 2 is the Secondary NetDisk
2. Enable the Aggregated / Mirrored NetDisk by se-
lecting either Enable Read/Write or Enable Read Only.
Enabled Aggregated / Mirrored NetDisk
- Enabled NetDisk is indicated by either a Blue or
Green circle. A Yellow circle signifies the secon-
dary NetDisk.
- Go to NetDisk Aggregation & Mirroring window.
Here, enabled NetDisk is indicated with Blue or Green colored NetDisk.
XIMETA, Inc
Aggregation
Aggregation
NetDisk Direct Attached Storage / NDAS
Mirroring
.
Mirroring
18
®
