Chapter 5 NetDisk Status and Mode Indicator
NetDisk provides users with six basic modes.
Below is a chart describing each of the NetDisk Modes and the icons that correspond with
each mode.
NetDisk
Icon
Color
Green
Blue
Red
Gray
White
Black
Yellow
XIMETA, Inc
NetDisk Icon
Read Only Mode
- Users can only read from NetDisk.
Read / Write Mode
- Users can read and write to NetDisk.
Unrecognized Mode
- NetDisk cannot be used.
- You can only remove this NetDisk from your
computer or view its property.
Disabled Mode
- NetDisk is disabled from your computer.
- NetDisk can be enabled back to Read Only Mode,
Read/Write Mode or removed from the PC
- NetDisk can be Aggregated or Mirrored.
Busy Mode
- NetDisk is busy performing a task or an
application is using NetDisk.
Disconnected Mode
- NetDisk is not connected to the network.
- Power Cord, Ethernet Cord or USB Cord is
unplugged. Once the cord is connected, you can
resume NetDisk use.
Bound Mode
- Bound disk used for Aggregation and Mirroring
only.
- You can only remove it from your computer or
view its property.
NetDisk Direct Attached Storage / NDAS
Mode / Meaning
