AW-HM610
802.11ah Module EVK
User Guide
Rev. 0.1
(For Standard)
1
FORM NO.: FR2-015_ A
Responsible Department：WBU
Expiry Date: Forever
The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or
disclosed in whole or in part without prior written permission of AzureWave.
Advertisement
Table of Contents
Related Manuals for AzureWave AW-HM610
Summary of Contents for AzureWave AW-HM610
- Page 1 (For Standard) FORM NO.: FR2-015_ A Responsible Department：WBU Expiry Date: Forever The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
- Page 2 NC Chen FORM NO.: FR2-015_ A Responsible Department：WBU Expiry Date: Forever The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
- Page 3 3. Basic Setup and Requirements for Host Mode ................ 8 FORM NO.: FR2-015_ A Responsible Department：WBU Expiry Date: Forever The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
- Page 4 This document supports the AW-HM610 (12 x 12 mm LGA Module). The AW-HM610 test board can be operated in MFG mode or Host Mode. If you want to perform AW-HM610 RF performance test, please contact the relevant personnel of Newracom to obtain NRC7394 Manufacturing Test Tool GUI (MFT GUI) and related user guide.
- Page 5 (TOP). The description of jumpers’ functions and settings on demo board is as follows: Azurewave AW-HM610 test board physical photo and PCB placement 2.1 Operation Mode Configurations AW-HM610 can be operated in MFG mode or Host Mode through the setting of jumper J4. J4 = L (Host Mode) J4 = H (MFG Mode) FORM NO.: FR2-015_ A...
- Page 6 The 5.0V power supply can be provided by USB connector (CON101) and short J10 c. The 3.3V power supply (J3) for AW-HM610 pin.9 VBAT is converted from the 5V power supply through the LDO on the demo board. You can measure the current of VBAT by connecting an ammeter in series with J3.
- Page 7 2.4 GPIOs and JTAG (J6) The GPIO pins of AW-HM610 are connected to J6, the definition of each pin is as follows FORM NO.: FR2-015_ A Responsible Department：WBU Expiry Date: Forever The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or...
- Page 8 3. Basic Setup and Requirements for Host Mode AW-HM610 can be connected to the Host side via SPI interface. The picture below is a photo of AW-HM610 demo board connected to Raspberry Pi4 via J11-B. Please note that the mode of J4, must be set correctly when operating in Host Mode.
