AW-NM333
IEEE 802.11 1X1 b/g/n Wireless LAN Module
Datasheet
Rev. 07
B01
CUSTOMER APPROVED SIGNATURE
AZUREWAVE
APPROVED SIGNATURE
Confirm
Approve
1
The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed
in whole or in part without prior written permission of AzureWave.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW-NM333 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AzureWave AW-NM333

Summary of Contents for AzureWave AW-NM333

  • Page 1 Datasheet Rev. 07 CUSTOMER APPROVED SIGNATURE AZUREWAVE APPROVED SIGNATURE Confirm Approve The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 2: Revision History

    Ver 0.7 2018/04/23 Rita Lu Josh Lin Add label and Silkscreen information The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 3: Table Of Contents

    5.3 The carton label………………………………..…………………………………………………..13 6.Installation guide........................14 7. Statement ........…………………………………………………………….………18 The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 4: Introduction

    IEEE 802.11 standard minimize the system power requirements by using AW- NM333. In addition to the support of WPA/WPA2 and WEP 64-bit and 128-bit encryption, the AW-NM333 also supports the IEEE 802.11i security standard through the implementation of Advanced Encryption Standard...

  • Page 5: Features

    Multiple power saving modes for low power consumption Antenna can be switched by RF switch connector The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 6: Specifications Table

    * If you have any certification questions about output power please contact FAE directly. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 7: Operating Conditions

    Operating Temperature Operating Humidity -55~125 ℃ Storage Temperature Storage Humidity 20%RH~70%RH The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 8: Pin Definition

    3.3V Power Supply 3.3V HOST_WKUP Host Wakeup 3.3V *Without internal pull-up resistor The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 9: Electrical Characteristics

    Input low voltage -0.4 0.3*V33 Output high voltage V33-0.4 Output low voltage The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 10: Mechanical Information

    4. Mechanical Information 4.1 Mechanical Drawing The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 11: Shipping Information

    100pcs/Tray 3 trays/Inner box, total 300pcs 2 inner boxes/Carton, total 600pcs The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 12: Package Information

    5.2 Package Information Rubber Band Desiccant Dry pack Bag The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 13: The Carton Label

    2-23330-XXX Customer Custmer P/N AW-NM333 Descrption Q'ty 600 pcs N.W. G.W. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 14: Installation Guide

    Installation guide 1. Please use NB & 1 pcs 2.4G AP 2. Test Configuration 3. Open the Terminal after the system is turned on ※※ The next steps are important: ※※ 4. select Wi-Fi icon Click Edit and delete wired...
  • Page 15 ※※ The next steps are important: ※※ (1) Test Tool (A) connection USB Cable with PC/NB (2) Test Tool (B) connection USB Cable with PC/NB (3) Test Tool (A) & Test Tool (B) connection 6. Open Ubuntu,press Ctrl+Alt+T open Terminal Key in command 7.
  • Page 16 iwlist mlan0 scan //scan AP ,check have scan TEST2 iwconfig mlan0 essid Cisco2 //join AP ifconfig mlan0 192.168.0.100 //set Wireless IP ping 192.168.0.1 //ping AP IP。 ※※ Important: During testing or when testing is completed to turn off the EUT, follow these steps: Step 1: please NB (2)”...

  • Page 18: Statement

    Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 19 Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 20 cm is maintained between the antenna and users, and The transmitter module may not be co-located with any other transmitter or antenna.
  • Page 20 Industry Canada statement: This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 21 IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the Canada authorization is no longer considered valid and the IC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate Canada authorization.
  • Page 22 低功率電波輻射性電機管理辦法 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或 使用者均不得擅自變更頻率、加大功率或變更原設計之特性及 功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經 發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續 使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率 射頻電機須忍受合法通信或工業、科學及醫療用電波輻 射性 電機設備之干擾。 1. 本模組於取得認證後將依規定於模組本體標示審驗合格標籤。 2. 系統廠商應於平台上標示「本產品內含射頻模組： XXXyyyLPDzzzz-x」字樣。...
