AzureWave AW-NM230NF-H User Manual

Ieee 802.11 b/g/n wireless lan and bluetooth combo m.2 1216 module
Hide thumbs

Advertisement

Quick Links

Download this manual
IEEE 802.11 b/g/n Wireless LAN and Bluetooth
Document
Date
release
Version 0.1
2015/03/10
Version 0.2
2015/8/3
1. WLAN Basic Test
Driver Installation
Throughput Test
RF Tx/Rx Performance Test
2. Bluetooth Basic Test
Download Mini-driver
Throughput Test
RF Performance Test
3. Statement
4. Pin definition/Pin map
AW-NM230NF-H
Combo M.2 1216 Module
User Guide
Modification
Initial Version
Add pin definition , pin map
- 1 -
Initials
Approved
Chao Lee
Amos Fu
Chao Lee
Amos Fu

Advertisement

loading
Need help?

Need help?

Do you have a question about the AW-NM230NF-H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AzureWave AW-NM230NF-H

Summary of Contents for AzureWave AW-NM230NF-H

  • Page 1 AW-NM230NF-H IEEE 802.11 b/g/n Wireless LAN and Bluetooth Combo M.2 1216 Module User Guide Document Date Modification Initials Approved release Version 0.1 2015/03/10 Initial Version Chao Lee Amos Fu Version 0.2 2015/8/3 Add pin definition , pin map Chao Lee Amos Fu 1.

  • Page 2: Connecting To Wireless Networks

    1. WLAN Basic Test **Must connect USB to PC Driver Installation DRIVER INSTALLATION (IN LINUX) •First prepare the Broadcom’s linux package, and put it in the “home”folder. •Open the Terminal, enter the command: sudo su and password. •Enter cd /home/username/drivername/src/dhd/linux •Enter make dhd-cdc-sdmmc-gpl to generate the dhd.ko file in /home/username/ drivername /src/dhd/linux/dhd-cdc-sdmmc-gpl-kernelversion...
  • Page 3 • BSSID: B2:51:28:6B:3C:A1 Capability: IBSS • Supported Rates: [ 1(b) 2(b) 5.5(b) 11(b) ] CONNECTING TO AN INFRASTRUCTURE NETWORK WITH NO SECURITY (AP CONNECTION) To connect to the network through an AP with SSID = Eval4325 Run wl join Eval4325. CONNECTING TO AN INFRASTRUCTURE NETWORK WITH WEP SECURITY To connect to the network that uses 12345 as the network key •...
  • Page 4 MEASURING THROUGHPUT USING NETIQ CHARIOT Test Procedure 1. Bring up the AW-NM230NF-H demo boar with the IP address set as 192.168.1.110. 2. Connect the reference computer with Chariot Console, which is assigned an IP address of 192.168.1.100, to the LAN...
  • Page 5 AP 3. Verify that communication exists between the reference computer and the AW-NM230NF-H demo board by pinging 192.168.1.100 from the AW-NM230NF-H host console. 4. Set up Chariot. a. On the host computer, activate EndPoint: b. Using Chariot Console on the reference computer, create two pair groups (192.168.1.100 and 192.168.1.110) using the Chariot Throughput.scr script.
  • Page 6 11g rate: ./wl mpc 0 ./wl country ALL ./wl up ./wl scansuppress 1 ./wl band b ./wl channel ./wl nrate -r ./wl txpwr1 -o -q ./wl phy_forcecal 1 ./wl pkteng_start 00:11:22:33:44:55 tx 300 1500 This will send continuous Tx Packets with 300 us packet interval,1500 byte packet length. Data rate =54Mbps ,Channel=7 and output power =15dBm(60/4=15 q means quarter).
  • Page 7 CREATING A Rx TEST (In Ubuntu linux 12.04) 1. Open the Terminal, enter the command: sudo su and password. 2. Enter Insmod /(path of dhd.ko file) firmware_path=/(path of firmware file) nvram_path=/(path of nvram file) to enable. 3. Enter the wl ver command to check the current WL driver version. 4.
  • Page 8 ./wl phy_forcecal 1 ./wl scansuppress 1 ./wl rxchain 1 ./wl reset_cnts ./wl counters This will enter Channel 7 receive mode. ※.The default MAC address is 001122334455. Packets sent from Signal Generator must have the same MAC address as the DUT’s MAC address (Runtime mac address can be overrode by using wl cur_etheraddr xx:xx:xx:xx:xx:xx . ※.
  • Page 9 4. In Select HCI Control Window Transport: a. Select UART as the type of transport. b. In the COM port list, select com6.(check the port number in device manager) - 9 -...
  • Page 10 c. In the Baud list, type 115200. d. Select the CTS flow control check box. e. Click OK. 5. In HCI Control, select the HCI protocol active check box 6. In the HCI Control commands list, select 0: Vendor-specific Commands (0 key), and then double-click Download Minidriver.
  • Page 11 7. On the Transport menu, click Download Firmware/Config. 8. In Select Download Firmware/Config Transport: a. Select UART as the type of transport. b. In the COM port list, select com6. c. In the Baud list box, type 115200. d. Select the CTS flow control check box. e.
  • Page 12 Throughput Test Bluetool contains a throughput test feature that can be used with two or more AW-NM230NF-H devices. Note that each device runs on a separate PC with BlueTool installed. This document will provide basic directions for setting-up and running this test.
  • Page 13 5. Double Click “Create Connection” and put BD address of the slave device into the BDADDR box. Click “OK” 6. In the “HCI Control” window,select”0 Vendor-specific commands”. Double Click ”Update UART Baud Rate”. Select 3000000 then click OK. A connection should establish now. This can be verified by looking in the log windows for both devices, which should now contain Connection Complete events with “Success”...
  • Page 14 RF Performance Test The following procedure explains how to configure the AW-NM230NF-H for RF testing using Broadcom BlueTool. At the completion of the procedure, connect the Bluetooth test instrument to the AW-NM230NF-H with RF cable and performs the RF tests.

  • Page 15: Important Note

    • In HCI Control, in the HCI Control commands list, select 7.6: Testing Commands (6 key), and then double-click Enable_Device_Under_Test_Mode. The AW-NM230NF-H is now ready to receive a connection request from the Bluetooth tester and begin testing specified RF parameters.
  • Page 16 This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna, 3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied firmware programming tool.
  • Page 17 Industry Canada statement: This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada.

  • Page 18: Note Importante

    This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required.
  • Page 19 Plaque signalétique du produit final Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs. Le produit final doit être étiqueté...
  • Page 20 Taiwan 警語： 第十二條→經型式認證合格之低功率射頻電機，非經許可，公司，商號或使用者均不得擅自變更頻率、加大功 率或變更原設計之特性及功能。 第十四條→低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並 改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電 波輻射性電機設備之干擾。 1. 本模組於取得認證後將依規定於模組本體標示審驗合格標籤 2. 系統廠商應於平台上標示「本產品內含射頻模組: CC XX xx YY yyy Z z W」字樣 - 20 -...
  • Page 21 4. Pin Definition / Pin Map Voltag Definition Basic Description Type No Connect Floating No Connect Floating No Connect Floating 3.3V 3.3V power pin 3.3V 3.3V 3.3V 3.3V power pin Ground. No Connect Floating No Connect Floating No Connect Floating No Connect Floating GPIO1...
  • Page 22 section in reset. This pin has an internal 200k ohm pull down resistor that is enabled by default. It can be disabled through programming. No Connect Floating No Connect Floating No Connect Floating Ground No Connect Floating No Connect Floating Ground No Connect Floating...
  • Page 23 UART_CTS High-Speed UART CTS 3.3V UART_OUT High-Speed UART Data Out 3.3V UART_IN High-Speed UART Data In 3.3V UART_RTS High-Speed UART RTS 3.3V PCM_SYNC PCM Synchronization control 3.3V PCM_IN PCM data Input 3.3V PCM_OUT PCM data Out 3.3V PCM_CLK PCM Clock 3.3V Ground Used by PMU to power up or power down the...
  • Page 24 Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground - 24 -...
  • Page 25 AW-NM230NF-H Top View Pin Map - 25 -...
