- Page 1 AW-WD089 Miracast WiFi Display HDMI module Operating SOP - 1 -...
- Page 2 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Important Note
antenna. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. - Page 4 Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Déclaration d'exposition aux radiations: Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé.
- Page 5 This device is intended only for OEM integrators under the following conditions: (For module device use) 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required.
-
Page 6: Note Importante
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the Canada authorization is no longer considered valid and the IC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate Canada authorization. - Page 7 Manuel d'information à l'utilisateur final L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module. Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme indiqué...
-
Page 8: Key Features
1. - Page 9 IEEE 802.11n 2x2 compliant Full IEEE 802.11a/b/g legacy compatibility with enhanced performance 2.4G/ 5GHz dual band selectable Comprehensive wireless network security support for WPA, WPA2‐PSK HDMI AV Output Interface Up to 1080p Video Resolution HDMI 1.3a with HDCP with secure key storage Support HDCP 2.1 Ultra low power operation Support WiDi 3.5/ 4.1 DLNA compliant, support following format Video Codecs – H.264, VC1, MPEG‐2, DiVX (MPEG‐4 part 2), WMV9 Containers – MP4, MOV, MKV, ASF, TS Audio Codecs – MP3, AAC, AC3, DTS Image – JPEG, PNG - 9 -...
-
Page 10: Block Diagram
2. Block Diagram 3. General Specifications Model Name AW‐WD089 Product Description Miracast HDMI module AP Broadcom BCM2835 RF SOC Broadcom BCM43236 PCB Dimension 65 x 20 x 1.6 mm Power Adaptor Voltage 5V Current 0.5A Video decode H.264 HP, MPEG‐2, MPEG‐4(SP and ASP), VC‐1 Format (H.264 HP can be up to 30 fps Full HD 1080p) Audio decode Format MP3, HE‐AAC Interfaces Support HDMI 1.3a with HDCP with secure key storage HDMI HDMI (type‐A) Male WLAN Standard IEEE 802.11a/b/g/n 802.11a/g/n: OFDM Modulation 802.11b: CCK(11, 5.5Mbps), DQPSK(2Mbps), BPSK(1Mbps) Frequency 2.4 GHz ISM radio band (2400 ~ 2500 MHz) - 10 -... - Page 11 5GHz ISM radio band (4900 ~ 5845MHz) 281.9mW for 2412 ~ 2462MHz 304.6mW for 5745 ~ 5825MHz Signal Strength 27.0mW for 5180 ~ 5240MHz Gain (dBi) Type Connector 2.4G 5.0G (Band 4) 5.0G (Band 1) Antenna PIFA I-PEX 4.13 4.23 6.45 Current Version H/W PCBA 02 F/W Broadcom Build 2.2RC1 (Miracast/ DLNA/ WiDi) Operation condition ...
- Page 12 c. After about 1 minute, it shows the following screen and ready for Miracast video streaming. Step 2: Touch the setting icon on the screen of S4/ Note 8.0. Picture for Samsung S4/ Note 8.0 desktop. - 12 -...
- Page 13 Step 3: Select “more settings”‐> “AllShare Cast” It shows all settings as following. - 13 -...
- Page 14 Step 4: On S4/ Note8.0, it shows the available device for Miracast receiver. Note: The naming rule for the Miracast receiver is the combination of monitor EDID and last two bytes of module MAC address. E.g. Acer‐B380 is only for example. If the EDID is Philips, the name should be Philips‐B380 for this module. - 14 -...
- Page 15 - 15 -...
- Page 16 Step 5: Touch the available Miracast receiver device and S4/ Note 8.0 is connecting to it as following picture. - 16 -...
- Page 17 Step 6: After few secondes, the S4/ Note 8.0 screen will be mirroring to the monitor as follows. - 17 -...
