AzureWave AW-CU300A V3 Getting Started Manual

Iot connectivity module for aws iot core
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AW-CU300A V3
IoT Connectivity Module for AWS IoT Core
Getting Started Guide
Rev. 0.2
1
The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or
disclosed in whole or in part without prior written permission of AzureWave.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW-CU300A V3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AzureWave AW-CU300A V3

Summary of Contents for AzureWave AW-CU300A V3

  • Page 1 IoT Connectivity Module for AWS IoT Core Getting Started Guide Rev. 0.2 The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 2 S.C Chueh Add introduction of “Over-the-Air 2021/10/28 Josh Lin Patrick Lin Updates” The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 3: Table Of Contents

    Publish and Monitor MQTT message on the cloud................13 Over-the-Air Updates ..........................15 The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 4: Introduction Of Aw-Cu300A V3

    Rich AT commands for end-device to communicate with AWS IoT Core The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 5: Block Diagram

    1.2 Block Diagram The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 6: Schematics

    3.3V GPIO_25 32KHz_CLK_IN 3.3V 3.3V(internal pull RESETN RESETN high 51k ohm) The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 7 NOTE (1): Dummy pin E4, E5, D6, D4, E3, and D5. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 8: Layout Guide And Smt Process Notification

    For mounting AW-CU300A V3 on your device, please refer to Layout Guide SMT Process Notification The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 9: Aws Command Example

    IOT knowledge. https://docs.aws.amazon.com/iot/latest/developerguide/iot-gs.html But, if you want to setup AzureWave AWS Connector, you would just refer to the following steps. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 10 Because they will be used when sending the AT+THING_Set command. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 11 You can find out thing name in Manage > Things submenu, and endpoint in settings of AWS IOT Console at console.aws.amazon/iot. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 12 The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 13: Publish And Monitor Mqtt Message On The Cloud

    2. Hardware Setup) and turn off the wireless devices near the AW-CU300A V3 (except for the device under test). Turn on the Wi-Fi module of the AW-CU300A V3 using AT+WIFI_On Step 2: Check if AW-CU300A V3 is in station mode using AT+WIFI_GetMode...
  • Page 14 You should see the message send from device as like below. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.

  • Page 15: Over-The-Air Updates

    If you want to find out your Account id, please enter the following link. https://console.aws.amazon.com/billing/home?#/account The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 16 Please enter AWS IOT console, choose Manager, and press Jobs and then press Create button. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 17 2. Please choice a FreeRTOS OTA update job and press “create OTA update job” The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 18 After that, you can select a exist firmware or upload a new image from local. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 19 Then, please enter slash in Pathname of firmware image on device and choose the Role we create on previous chapter. Then press NEXT button. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 20 5. Entering a unique ID in ID field. You can’t use the same ID you created before. Other fields just keep default setting and press Create button. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
  • Page 21 The Job will be in IN PROGRESS status. The information contained herein is the exclusive property of AzureWave and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of AzureWave.
