- Page 1 STV-680N, STV-680P ADJUSTABLE WALL MOUNT FOR FLAT SCREENS N Instruction manual...
- Page 2 - Arm with double articulation. - 180° horizontally adjustable. - 40 ° vertical tilt. - Spirit level. - Colour: STV-680N = black. STV-680P = silver. - Maximum borne weight: 25 kg. - Maximum arm length: 36 cm - Mount dimensions: plate 1 – 11 x 11 cm with 50/75/100 VESA regulation holes.
- Page 3 3.- The bracket is supplied with 3 plates for the screen. Choose the plate which coincides the best with the holes on your screen, in accordance with the VESA regulations. Plate 1 with VESA 50/75/100 can be used instead of plate 2. Plate 2 with VESA 50/75/100/200 can be used instead of plate 1.
- Page 4 5.- ATTACHING THE SCREEN TO THE MOUNT Firstly, choose the bolts and the necessary accessories to attach the screen to the mount. The mount is supplied with different diameter and length bolts. Find the attachment holes on the back of the screen and decide which bolt to use according to the diameter of the hole.
- Page 5 3.- Correct installation on the wall, or surface, is necessary to ensure that the mount supports the maximum weight. FONESTAR does not hold itself responsible, in any way, for damage or breakages that arise from the mount coming away from the surface due to a faulty surface, incorrect installation or handling.
- Page 6 This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
