- Page 1 STV-658N, STV-658P TILTING WALL MOUNT FOR FLAT SCREENS N Instruction manual...
- Page 2 - ±15º vertical tilt. - Distance to the wall in vertical position: 7.5 cm. - Spirit level. - Lock system. - Colour: STV-658N = black. STV-658P = silver. - Maximum borne weight: 60 kg. - Dimensions: Wall plate: 51.5 x 22.5 cm.
- Page 3 1.- FIXING THE MOUNT TO THE WALL 2.- ATTACHING THE SCREEN TO THE MOUNT - 3 -...
- Page 4 2.1.- Back of flat screen: 2.2.- Back of curved screen or screen with inset: - 4 - - 4 -...
- Page 5 4.- ADJUSTING THE TILT OF THE SCREEN - 5 -...
- Page 6 2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
