- Page 1 STV-661 ULTRASLIM VERTICAL WALL MOUNT FOR FLAT SCREENS INSTRUCTION MANUAL...
- Page 2 DESCRIPTION - Ultraslim vertical wall mount for flat screens between 37” and 70” (94 and 178 cm). - Screens installed vertically. - Distance to the wall: 3.2 cm. - Spirit level. - Lock system. - Colour: black. - Maximum borne weight: 75 kg. - Dimensions: Wall plate: 51.5 x 22.5 cm Adjustable width from 4 to 47 cm x 77 cm height...
- Page 3 1.- FIXING THE MOUNT TO THE WALL - 3 -...
- Page 4 2.- ATTACHING THE SCREEN TO THE MOUNT 2.1.- Back of the flat screen 2.2.- Back of the curved screen or with inset - 4 - - 4 -...
- Page 5 5.- LOCK SYSTEM - 5 -...
- Page 6 2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
