PRODUCT ASSEMBLY INSTRUCTIONS
Instructions
•
Step 1:
Place the post on a safe surface where the table can not be scratched or damaged.
•
Step 2:
Align the supporting panel with the post holes as seen.
•
Step
3:Use (4) bolt (M8 x 30) to tighten the supporting panel and the post with the Allen Key. Repeat until all 4
sides are bolted
•
Step 4:
Use (4) spacers and (4) bolt (M8 x 30) to tighten the supporting panel and the table top with the Allen
Key. Repeat until all 4 sides are bolted
Item#: T20871R-B
Helpers needed to assemble: 2
Estimate time frame to assemble: 30 minutes
#
1
post
2
Supporting
panel
3
Bolt(M8*30)
4
Allen Key
5
Tabletop
6
Spacer
•
Step 5:
Test the table is firmly on the ground and the
table does not wiggle.
•
Step 6:
Enjoy your new table.
Description
Quantit
y
1
1
8
1
1
4
