Step 1:
On the top of the plate use (4) spacers and (4) bolt (M6 x 20 ) to tighten the top portion of the plate with the Allen
Key. Repeat until all 4 sides are bolted.
•
Step 2:
Turn the dining chair legs upside down to tighten the swivel plate
•
Step 3:
Once the swivel is secure, we will add the seat under the dining chair to connect the seat to the legs.
•
Step 4:
Flip the dining chair over upright as seen.
•
Step 5:
Test the dining chair is firmly on the ground and the seat does not wiggle.
•
Step 6:
Sit and enjoy your new dining chair.
Product Assembly Instructions
Item#: DC17477G-B
Helpers needed to assemble: 2
Estimate time frame to assemble: 20 minutes
#
1
2
3
4
Bolt(M6X20)
5
underneath.
Description
Quantity
legs
1
Seat
1
Spacer
4
4
Allen Key
2
