- Page 1 Product Assembly Instructions Item # LCMUBDGRKGB NOT PROVIDED...
- Page 2 A: Headboard x 1 B: Footboard x 1 C: Side Panel x 2 D: Middle bar x 2 E: Slats x 16 F: Leg x 2 G: Support Leg x 4 H: Bolt / M6*20 x 18 L: Bolt M6*35 P: Threaded Rod M8*70 x 2 I: Flat Washer / Ø19 x 24...
- Page 3 Step 1 : Turn the Footboard (B) over and place it on the ground where the exterior finish will not be scratched. Align the screw holes on the Footboard(B) with the screw holes of Legs (F). Insert flat washers (I) lock washer (J) and bolt (H) into each hole. Once the screws are in place,tighten the screw until firmly attached with the allen-wrench (K) provided.
- Page 4 HEAD FOOT Step 5 : Under position connect Footboard(B) with Side Panel(C). Insert Semicircle Washer(N), Flat Washer(I), Lock Washer(J), Nut(M) with Threaded Rod(P). Tighten the screw until firmly attached with the wrench(R) provided. Step 6 : Under position connect Headboard(A) with Side Panel(C). Insert Semicircle Washer(N), Flat Washer(I), Lock Washer(J), Nut(M) with Flat Washer(I), Lock Washer(J) and Bolt(O).
- Page 5 Step 8 : Put on slats into the frame. Insert the screws (Q) into each hole. Once the screws are in place,tighten the screw until firmly attached with the screwdriver. Finished...
