- Page 1 M -35U-E P.A. AMPLIFIER USB/MP3 INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DESCRIPTION P. A. amplifier with USB player, 30 W maximum, 15 W RMS. 4, 8 and 16 Ω and high impedance 100 V line. Suitable for small P. A. installations and installations in vehicles. Special version with automatic playback through remote control. USB player with special characteristics for playing files automatically when it is activated using the REMOTE button or using relay with the push button sequence (contacts open, closed and open). -
Page 5: Back Panel
16.- Play/pause button. 17.- POWER: on/off button for the USB player and for stopping playback. Press this button for 3 seconds to switch the USB player on or off. BACK PANEL 1.- COM 4, 8 and 16 Ω: output terminals for 4, 8 and 16 Ω low impedance speakers. Connect the line between the COM terminal and the desired impedance. - Page 6 CONNECTION Connect the speakers to the speaker output. Use the 4-8-16Ω low impedance output or the 100 V high line impedance, according to the type of speakers you are going to connect. Do not use both types of output at the same time.
-
Page 7: Technical Specifications
EXAMPLE OF A 100V LINE HIGH IMPEDANCE CONNECTION TECHNICAL SPECIFICATIONS MA-35U-E CHARACTERISTICS PA amplifier. USB/MP3 player. Emergency or message reproduction mode and automatic playback function through button/relay or amplifier power switch. PLEASE ENQUIRE. Vehicle and tabletop assembly. POWER 30 W maximum, 15 W RMS RESPONSE 50-15,000 Hz ±3 dB... -
Page 8: Warranty
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
