*15G065287000AK*
P/N: 15G065287000AK V1.0
Quick Installation Guide
SP2C741D16X-2T
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1.
Unplug the power cord from the wall socket before touching any components.
2.
To avoid damaging the server board's components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3.
Hold components by the edges and do not touch the ICs.
4.
Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5.
When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
2
Motherboard Layout
1
2
3
PSU_SMB1
ATX12V2
DDR5_P1
DDR5_O1
FRNT_VGA1
DDR5_N1
DDR5_M1
59
LAN1
LAN2
UID1
DDR5_I1
58
DDR5_J1
57
DDR5_K1
DDR5_L1
56
55
X710-AT2
54
53
ASPEED
AST2600
52
51
NMI_BTN1
49
50
3
I/O Panel
1
No. Description
1
VGA Port (VGA1)
2
USB 2.0 Ports (USB_1_2)
3
LAN RJ-45 Port (IPMI_LAN)
6
4
5
7
8
9
CPU1_HSBP1
CPU0_HSBP1
FAN2
FAN1
CPU1
PCIE6
SP2C741D16X-2T
PCIE5
PCIE4
PCIE3
PCIE2
NUT2280_1
PCIE1
Dr. Debug
NUT22110_1
PCIE0
COM1
IPMB_1 BMC_SMB_1 BMC_SMB_2
48
47
45
46
3
4
5
6
2
No. Description
4
10G LAN RJ-45 Port (LAN1)
5
10G LAN RJ-45 Port (LAN2)
6
UID Switch (UID1)
1
Install the Server Board
1
Insert the server board into the chassis.
2
A f f i x t he screws clock w ise into t he
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
10
11
35.6 cm (14 in)
ATXPWR1
ATX12V1
DDR5_D1
DDR5_C1
DDR5_B1
DDR5_A1
CPU0
DDR5_E1
DDR5_F1
DDR5_G1
DDR5_H1
M2_1
OCU2
Intel C741
FAN7
FAN8
BAT1
CLRMOS1
USB3_1_2
TPM_BIOS_PH1
PANEL1
ME_RECOVERY1
FLASH_OVERRIDE1
PASSWORD_CLEAR1
BIOS_OVERRIDE1
RAID_1
AUX_PANEL1
SATA_SGPIO2
SATA_SGPIO1
43
42
41
40
39
38
37
36
35
34
44
No.
Description
45
BMC SMBus Header (BMC_SMB_1)
Intelligent Platform Management Bus Header
46
(IPMB_1)
47
COM Header (COM1)
48
Clear CMOS Pad (CLRMOS1)
49
PCI Express 5.0 x16 Slot (PCIE0)
Non Maskable Interrupt Button
50
(NMI_BTN1)
51
PCI Express 5.0 x8 Slot (PCIE1)
52
PCI Express 5.0 x16 Slot (PCIE2)
53
PCI Express 5.0 x16 Slot (PCIE3)
54
PCI Express 5.0 x16 Slot (PCIE4)
55
PCI Express 5.0 x16 Slot (PCIE5)
56
PCI Express 5.0 x16 Slot (PCIE6)
2 x 288-pin DDR5 DIMM Slots
57
(DDR5_J1, DDR5_L1)
2 x 288-pin DDR5 DIMM Slots
58
(DDR5_I1, DDR5_K1)
59
LGA 4677 CPU Socket (CPU0)
www.asrockrack.com
No.
Description
12
1
Front VGA Header (FRNT_VGA1)
2
PSU SMBus Header (PSU_SMB1)
3
ATX 12V Power Connector (ATX12V2)
PWM_CFG1
Backplane PCI Express Hot-Plug Connector
4
13
(CPU1_HSBP1)
Backplane PCI Express Hot-Plug Connector
14
5
(CPU0_HSBP1)
6
System Fan Connector (FAN2)
7
System Fan Connector (FAN1)
2 x 288-pin DDR5 DIMM Slots
8
(DDR5_N1, DDR5_P1)
15
2 x 288-pin DDR5 DIMM Slots
9
(DDR5_M1, DDR5_O1)
10
ATX Power Connector (ATXPWR1)
11
ATX 12V Power Connector (ATX12V1)
12
PWM Configuration Header (PWM_CFG1)
16
2 x 288-pin DDR5 DIMM Slots
13
(DDR5_B1, DDR5_D1)
17
2 x 288-pin DDR5 DIMM Slots
14
MCIO2
(DDR5_A1, DDR5_C1)
18
19
15
LGA 4677 CPU Socket (CPU0)
MCIO1
20
2 x 288-pin DDR5 DIMM Slots
21
16
(DDR5_E1, DDR5_G1)
SATA0
22
OCU3
2 x 288-pin DDR5 DIMM Slots
23
17
OCU1
(DDR5_F1, DDR5_H1)
24
25
FAN5
FAN3
18
Mini Cool Edge IO Connector (MCIO2)
26
27
19
M-key M.2 Socket (M2_1) (Type 2280/22110)
FAN6
FAN4
28
20
Mini Cool Edge IO Connector (MCIO1)
29
30
21
OCuLink Connector (4 SATA 6Gb/s) (OCU3)
31
ATX12V3
22
SATA Connector (SATA0)
32
23
OCuLink Connector (4 SATA 6Gb/s) (OCU2)
ATX12V4
33
24
OCuLink Connector (4 SATA 6Gb/s) (OCU1)
25
System Fan Connector (FAN7)
26
System Fan Connector (FAN3)
27
System Fan Connector (FAN5)
28
System Fan Connector (FAN4)
29
System Fan Connector (FAN6)
30
USB 3.2 Gen1 Header (USB3_1_2)
31
System Fan Connector (FAN8)
32
ATX 12V Power Connector (ATX12V3)
33
ATX 12V Power Connector (ATX12V4)
34
Auxiliary Panel Header (AUX_PANEL1)
35
System Panel Header (PANEL1)
36
Virtual RAID On CPU Header (RAID_1)
BIOS Swap Override Jumper
37
(BIOS_OVERRIDE1)
Flash Override Jumper
38
(FLASH_OVERRIDE1)
39
SATA SGPIO Connector (SATA_SGPIO1)
Password Reset Jumper
40
(PASSWORD_CLEAR1)
41
SATA SGPIO Connector (SATA_SGPIO2)
42
ME Recovery Jumper (ME_RECOVERY1)
43
TPM-SPI Header (TPM_BIOS_PH1)
44
BMC SMBus Header (BMC_SMB_2)
SP2C741D16X-2T
