ASROCK Rack SP2C741D16-2T Quick Installation Manual

*15G065332001AK*
P/N: 15G065332001AK V1.1
Quick Installation Guide
SP2C741D16-2T
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board's components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
2 Motherboard Layout
1 2
ATX12V2
PSU_SMB1
CPU1_HSBP1
DDR5_P1
DDR5_O1
DDR5_N1
DDR5_M1
UID1
59
LAN1
LAN2
DDR5_I1
58
DDR5_J1
57 DDR5_K1
DDR5_L1
56
55
54
X710AT2
53
52
CPLD
NMI_BTN1
51
3 I/O Panel
2
1 3
No. Description
1 USB 2.0 Ports (USB_1_2)
2 LAN RJ-45 Port (IPMI_LAN)
3 VGA Port (VGA1)
3 4 5
CPU1
PCIE6
SP2C741D16-2T
PCIE5
PCIE4
ASPEED
PCIE3
AST2600
PCIE2
PCIE1
COM1
BMC_SMB_1 BMC_SMB_2 FRNT_VGA1 IPMB_1
Dr. Debug
50 49 48 47 46 45
4 5 6
No. Description
4 UID Switch (UID1)
10G LAN RJ-45 Port
5
(LAN1, shared NIC)
6 10G LAN RJ-45 Port (LAN2)
1 Install the Server Board
1
Insert the server board into the chassis.
2
A f f i x t he screws clock w ise into t he
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
6 7
33.78 cm (13.3 in)
PWM_CFG1
BAT1
ATX12V1
ATXPWR1
DDR5_D1
DDR5_C1
DDR5_B1
DDR5_A1
CPU0
DDR5_E1
DDR5_F1
DDR5_G1
DDR5_H1
MCIO1
M2_1
OCU3
OCU2
Intel C741
FAN1 FAN2
FAN3 FAN4
NUT2280_1
FAN5 FAN6
CLRMOS1
TPM_BIOS_PH1
TSYNC1
FAN7 FAN8
TSYNC2
ATX12V4
RAID_1
NUT22110_1
AUX_PANEL1 PANEL1
PASSWORD_CLEAR1 SATA_SGPIO2 SATA_SGPIO1
FLASH_OVERRIDE1 ME_RECOVERY1
BIOS_OVERRIDE1
44 43 42 41 40 39 38 37 36 35 34 33 32 31
No. Description
44 Clear CMOS Pad (CLRMOS1)
45 COM Header (COM1)
Intelligent Platform Management Bus
46
Header (IPMB_1)
47 Front VGA Header (FRNT_VGA1)
48 BMC SMBus Header (BMC_SMB_2)
49 BMC SMBus Header (BMC_SMB_1)
Non Maskable Interrupt Button
50
(NMI_BTN1)
51 PCI Express 5.0 x16 Slot (PCIE1)
52 PCI Express 5.0 x8 Slot (PCIE2)
53 PCI Express 5.0 x16 Slot (PCIE3)
54 PCI Express 5.0 x16 Slot (PCIE4)
55 PCI Express 5.0 x16 Slot (PCIE5)
56 PCI Express 5.0 x16 Slot (PCIE6)
2 x 288-pin DDR5 DIMM Slots
57
(DDR5_J1, DDR5_L1)
2 x 288-pin DDR5 DIMM Slots
58
(DDR5_I1, DDR5_K1)
59 LGA 4677 CPU Socket (CPU1)
www.asrockrack.com
No. Description
8
1 PSU SMBus Header (PSU_SMB1)
2 ATX 12V Power Connector (ATX12V2)
Backplane PCI Express Hot-Plug Connector
3
CPU0_HSBP1
(CPU1_HSBP1)
9
2 x 288-pin DDR5 DIMM Slots
10
4
(DDR5_N1, DDR5_P1)
11
2 x 288-pin DDR5 DIMM Slots
5
(DDR5_M1, DDR5_O1)
6 ATX Power Connector (ATXPWR1)
7 PWM Configuration Header (PWM_CFG1)
8 ATX 12V Power Connector (ATX12V1)
Backplane PCI Express Hot-Plug Connector
12
9
(CPU0_HSBP1)
2 x 288-pin DDR5 DIMM Slots
10
(DDR5_B1, DDR5_D1)
2 x 288-pin DDR5 DIMM Slots
11
(DDR5_A1, DDR5_C1)
12 LGA 4677 CPU Socket (CPU0)
13
2 x 288-pin DDR5 DIMM Slots
13
14
(DDR5_E1, DDR5_G1)
2 x 288-pin DDR5 DIMM Slots
15
MCIO2 14
(DDR5_F1, DDR5_H1)
16
15 Mini Cool Edge IO Connector (MCIO2)
17
18
16 Mini Cool Edge IO Connector (MCIO1)
SATA0
19 M-key M.2 Socket (M2_1)
17
20
(Type 2280/22110)
OCU1
21
22 OCuLink Connector (4 SATA 6Gb/s)
23
18
USB3_1_2
(OCU3)
24
19 SATA Connector (SATA0)
25
ATX12V3
OCuLink Connector (4 SATA 6Gb/s)
26
20
27
(OCU2)
28
OCuLink Connector (4 SATA 6Gb/s)
29
21
(OCU1)
22 System Fan Connector (FAN1)
23 System Fan Connector (FAN2)
30
24 USB 3.2 Gen1 Header (USB3_1_2)
25 System Fan Connector (FAN4)
26 ATX 12V Power Connector (ATX12V3)
27 System Fan Connector (FAN6)
28 ATX 12V Power Connector (ATX12V4)
29 System Fan Connector (FAN8)
30 System Panel Header (PANEL1)
31 System Fan Connector (FAN7)
32 Auxiliary Panel Header (AUX_PANEL1)
33 TGPIO Headers (TSYNC1, TSYNC2)
34 Virtual RAID On CPU Header (RAID_1)
35 SATA SGPIO Connector (SATA_SGPIO1)
36 System Fan Connector (FAN5)
37 SATA SGPIO Connector (SATA_SGPIO2)
38 System Fan Connector (FAN3)
39 ME Recovery Jumper (ME_RECOVERY1)
BIOS Swap Override Jumper
40
(BIOS_OVERRIDE1)
Flash Override Jumper
41
(FLASH_OVERRIDE1)
Password Reset Jumper
42
(PASSWORD_CLEAR1)
43 TPM-SPI Header (TPM_BIOS_PH1)
SP2C741D16-2T
