ASROCK Rack EP2C6212D16NM Quick Installation Manual

*15G065099000AK*
P/N: 15G065099000AK V1.0
Quick Installation Guide
EP2C6212D16NM
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board's components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
2 Motherboard Layout
1 2 3 4 5
SSATA_4
SATAPWR1
1
SATA_0_7
PMBUS_SEL_CLK1
57
PMBUS_SEL_ALT1
SSATA_0_3
Intel
1
FRNT_VGA1
C622
UID1 Dr.
BIOS
Debug
ROM
56
1
FRONT_LED_LAN34
MEZZ_MB_B1
55
MEZZ_1_C1
54
RoHS
53
MEZZ_MB_A1
52 PCIE7
EP2C622D16NM
51
PCIE6
50
BMC
NUT30 NUT42
49
MEZZ_MB_B2
48
PECI1
Super
I/O
47
46
MEZZ_MB_A2
45
CHASSIS_ID0
CHASSIS_ID1 ME_RECOVERY1
CHASSIS_ID2
44
1 1 1 1
1
1 1
1
USB3_3_4 TPM1
USB3_5 BMC_SMB_1 IPMB_1
43 42 41 40 39 38
3 I/O Panel
2
3 4
1
5 Headers
System Panel
PLED+
PLED-
PWRBTN#
GND
1
GND
RESET#
GND
HDLED-
HDLED+
6 7 8 9 10
ATXPWR1
1 1 1
PSU_SMB1
NCSI_SEL1
1 1
PMBUS_SEL_DAT1
(Blue)
(White)
NUT60 NUT80
BATTERY1
OCU2
PANEL1
T 1 R NMI_BTN1
1
PLED PWRBTN
1
OCU1
1
1 1
AUX_PANEL1 HDLED RESET SPEAKER
37 36 35 34 33 32 31
No. Description
1 USB 3.0 Ports (USB3_1_2)
2 LAN RJ-45 Port (IPMI_LAN1)
3 VGA Port (VGA1)
4 UID Switch (UID)
Auxiliary Panel
A B
1
C D E
1 Install the Server Board
1
Insert the server board into the chassis.
2
A f f i x t he screws clock w ise into t he
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
33.02 cm (13 in)
DDR4_C1 (64 bit, 288-pin module, Blue)
DDR4_B1 (64 bit, 288-pin module, Blue)
DDR4_A1 (64 bit, 288-pin module, Blue)
DDR4_A2 (64 bit, 288-pin module, White)
ATX12V1
CPU1
REAR_FAN1
REAR_FAN2
CPU1_FAN1
DDR4_D2 (64 bit, 288-pin module, White)
DDR4_D1 (64 bit, 288-pin module, Blue)
DDR4_E1 (64 bit, 288-pin module, Blue)
DDR4_F1 (64 bit, 288-pin module, Blue)
DDR4_I1 (64 bit, 288-pin module, Blue)
DDR4_H1 (64 bit, 288-pin module, Blue)
DDR4_G1 (64 bit, 288-pin module, Blue)
DDR4_G2 (64 bit, 288-pin module, White)
FRNT_FAN1
FRNT_FAN2
FRNT_FAN3
CPU2
FRNT_FAN4
CPU2_FAN1
ATX12V2
DDR4_J2 (64 bit, 288-pin module , White )
DDR4_J1 (64 bit, 288-pin module , Blue )
DDR4_K1 (64 bit, 288-pin module , Blue )
DDR4_L1 (64 bit, 288-pin module, Blue)
4 Jumper Cap On/Off
When the jumper cap is placed on the pins, the
jumper is "Short". If no jumper cap is placed on the
pins, the jumper is "Open".
The illustration shows a 3-pin jumper whose pin1
and pin2 are "Short" when a jumper cap is placed on
these 2 pins.
www.asrockrack.com
1 Mini-SAS HD Connector (SSATA_0_3)
2 Mini-SAS HD Connector (SATA_0_7)
3 PMBUS Mode Jumper (PMBUS_SEL_ALT1)
4 SATA DOM Power Jumper (SATAPWR1)
5 SATA DOM Connector, Red (SSATA_4)
6 PMBUS Mode Jumper (PMBUS_SEL_CLK1)
11
7 NCSI Mode Jumper (NCSI_SEL1)
8 ATX Power Connector (ATXPWR1)
12
9 PSU SMBus (PSU_SMB1)
13
10 PMBUS Mode Jumper (PMBUS_SEL_DAT1)
3 x 288-pin DDR4 DIMM Slots
11
14 (DDR4_A1, DDR4_B1, DDR4_C1, Blue)*
12 1 x 288-pin DDR4 DIMM Slots (DDR4_A2, White)
15
13 ATX 12V Power Connector (ATX12V1)
14 LGA 3647 CPU Socket P0 (CPU1)
16
15 Rear Fan Connector (REAR_FAN1)
17
16 Rear Fan Connector (REAR_FAN2)
18
17 CPU1 Fan Connector (CPU1_FAN1)
18 1 x 288-pin DDR4 DIMM Slots (DDR4_D2, White)
19
3 x 288-pin DDR4 DIMM Slots
19
(DDR4_D1, DDR4_E1, DDR4_F1, Blue)*
3 x 288-pin DDR4 DIMM Slots
20
(DDR4_G1, DDR4_H1, DDR4_I1, Blue)*
20
21 1 x 288-pin DDR4 DIMM Slots (DDR4_G2, White)
21
22 Front Fan Connector (FRNT_FAN1)
22
23 Front Fan Connector (FRNT_FAN2)
24 Front Fan Connector (FRNT_FAN3)
23
25 LGA 3647 CPU Socket P0 (CPU2)
24
25 26 Front Fan Connector (FRNT_FAN4)
26
27 CPU2 Fan Connector (CPU2_FAN1)
28 ATX 12V Power Connector (ATX12V2)
27
29 1 x 288-pin DDR4 DIMM Slots (DDR4_J2, White)
28 3 x 288-pin DDR4 DIMM Slots
30
(DDR4_J1, DDR4_K1, DDR4_L1, Blue)
29
31 OCuLink x4 Connector (OCU2)
32 OCuLink x4 Connector (OCU1)
30
33 Non Maskable Interrupt Button (NMI_BTN1)
34 Speaker Header (SPEAKER1)
35 System Panel Header (PANEL1)
36 Auxiliary Panel Header (AUX_PANEL1)
37 Thermal Sensor Header (TR1)
38 TPM Header (TPM1)
39 Intelligent Platform Management Bus header (IPMB1)
40 Chassis ID1 Jumper (CHASSIS_ID1)
41 BMC SMBus Header (BMC_SMB_1)
42 Vertical Type A USB 3.0 (USB3_5)
43 BMC SMBus Header 1 (BMC_SMB1)
44 Chassis ID2 Jumper (CHASSIS_ID2)
45 Chassis ID0 Jumper (CHASSIS_ID0)
46 Mezzanine Slot (MEZZ_MB_A2)*
47 ME Recovery Jumper (ME_RECOVERY1)
48 CPU PECI Mode Jumper (PECI1)
49 Mezzanine Slot (MEZZ_MB_B2)*
50 M.2 Slot (M2_2)
51 PCI Express 3.0 Slot (PCIE6)
52 PCI Express 3.0 Slot (PCIE7)
53 Mezzanine Slot (MEZZ_MB_A1)
54 Mezzanine Slot (MEZZ_1_C1)
55 Mezzanine Slot (MEZZ_MB_B1)
56 Front LAN LED Header (FRONT_LED_LAN34)
57 Front VGA Header (FRONT_VGA1)
*Only supports ASRockRack storage cards.
