*15G065158000AK*
P/N: 15G065158000AK V1.0
Quick Installation Guide
1U10E-ROME/2T
System Overview
2
3
1
5
6
7
13
14
15
SATA & SGPIO Cable Connections
Server Board
SLIMLINE to SATA Cable
L: 950mm
SATA Cable
L: 1000mm
SATA10
SATA8
SATA9
SATA7
Backplane (BPB)
4
8
9
10
11
12
16
17
18
SATA.1~6
SATA7~10
SMBus Cable
L: 520mm
SMBus
SATA6
SATA4
SATA2
SATA5
SATA3
No.
Item
1
Server Board (ROMED8QM-2T)
2
LAN Mezzanine Card
3
Riser Board x16 Placement (for PCIE6 slot on the server board)
4
2 x Power Supply Units
5
System Fan1, 4056
6
System Fan2, 4056
7
System Fan3, 4056
8
System Fan4, 4056
9
System Fan5, 4056
10
System Fan6, 4056
11
Power Distribution Board (PDB)
12
Backplane Board (BPB)
13
Front Panel Board (FPB)
14
2 x 2.5" HDD Trays (HDD1 / HDD2)
15
2 x 2.5" HDD Trays (HDD3 / HDD4)
16
2 x 2.5" HDD Trays (HDD5 / HDD6)
17
2 x 2.5" HDD Trays (HDD7 / HDD8)
18
2 x 2.5" HDD Trays (HDD9 / HDD10)
Front Panel View (HDD Trays)
HDD2
HDD1
SLIMLINE Cable Connections
Server Board
SLIMLINE5
SATA1
Backplane (BPB)
HDD4
HDD6
HDD8
HDD3
HDD5
HDD7
SLIMLINE2
SLIMLINE Cables L: 500mm
SLIMLINE4
SLIMLINE3
SLIMLINE2
HDD10
HDD9
SLIMLINE1
SLIMLINE4
SLIMLINE5
SLIMLINE3
SLIMLINE1
