Tektronix TEK 7020 Manual

TEK
INTERFACING
INFORMATION
GPIB
MADE EASY
7020 Instrument
Interfacing Guide
1728·01
This Interfacing Guide is designed to help you get
started using the 7020 Programmable Oigitizer on the
GPIB as quickly and easily as possible. This IIG pro-
vides information on setting up the 7020 for GPIB
operation as well as some program examples that il-
lustrate the communication with the 7020. This guide
is not intended to take the place of the 7020 Oper-
ators Manual or the manuals for your controller.
CONNECTING TO THE SYSTEM
Attach the 7020 to the GPIB using a standard
GPIB cable. The 7020 can be connected to the bus
from either the front-panel GPIB connector or when
installed in a R7603/ option 20 mainframe, from the
rear-panel GPIB connector. Note, when using the
7020 with the R7603 Option 20, be sure the jumper
cable (Part number 175-7151-00) is installed in the
7020.
For additional copies, order
070-1728-00
First Printing APR 1983
COMMITTED TO EXCElLENCE
