Sentec IPV-2C Quick Reference Manual page 4

Digital Display
Mean Airway Pressure
(MAP) is the average
pressure (amplitude +
CPAP) in the lung over
5 seconds.
Usage Timer displays the
total time of the current
usage.
NOTE: Display numbers are
for reference only.
PAC-SAL-LIT-733 (1)
2024-01
Pulse Frequency Rate
represents the number of
pulses per minute.
Pulsating Bar Graph
D
measuring pulse amplitude
(0-50 cmH O). PEEP is
2
represented by a solid bar
at the base and Average
Inspiratory Pressure (AIP)
is represented by the
pulsating peaks of the Bar
Graph display.
Troubleshooting
Digital display off
The IPV® pressure must be > 2.5 cmH
before the display turns on. Consider occluding the end
of the Phasitron, allowing the Digital Display to read 2.5
cmH O to wake digital display. Check connections and/or
2
the digital display battery.
Nebulizer not aerosolizing
Ensure there is liquid present in the nebulizer cup and check
for flow out of the nebulizer baffle. Disconnect the yellow
tubing and verify flow. If flow is present, turn the Master
Switch to the OFF position and reconnect the yellow tubing
to the nebulizer bowl. If the issue persists, contact product
support.
Slow or no percussions
Check that the inlet gas source is properly connected.
Check the device to ensure the Master Switch is in the ON
position, make sure Inspiratory Flow knob is not in the OFF
position, and adjust Frequency knob for a higher rate.
Finally, check the green REMOTE connector for blockage. If
issue persists, contact service.
NOTE:
Refer to the Instruction Manual for the
IPV®-2C for warnings, cautions, and additional
information. Always follow hospital protocol and
use good clinical judgement when delivering IPV®
therapy. Absolute contraindications for IPV®
usage include untreated tension pneumothorax
and/or an untrained or unskilled operator.
