IPV
Before you start
Assembling Phasitron
Place a maximum of 20 ml of normal
saline or prescribed medication in the
nebulizer cup.
Connect yellow tubing quick-connect
fitting to nebulizer cup.
Connect clear tubing quick-connect
fitting to the cap.
Press red tubing onto connector.
Connect blue corrugated tubing to
exhalation port.
Connect the tubing to the
corresponding-colored connectors.
Do not obstruct green remote port
Ensure Master Switch is OFF.
Then, connect the IPV® to a 50 psi
gas source.
-2C Quick Reference Guide
®
Patient Connections
Mouthpiece
Instruct patient to keep
lips and cheeks splinted
to ensure the pulses are
directed into the lungs.
Mask
It is recommended
to use a resuscitation
mask or similar non-
vented mask.
Direct
The Phasitron can be
attached directly to
an artificial airway or
airway adaptor.
NOTE: For patients under five
years of age without an artificial
airway, mask configuration is
recommended
Advertisement
Related Manuals for Sentec IPV-2C
Summary of Contents for Sentec IPV-2C
- Page 1 -2C Quick Reference Guide ® Before you start Assembling Phasitron Patient Connections Place a maximum of 20 ml of normal Mouthpiece saline or prescribed medication in the Instruct patient to keep nebulizer cup. lips and cheeks splinted to ensure the pulses are Connect yellow tubing quick-connect directed into the lungs.
- Page 2 Controls + Starting Settings Master Switch turns the IPV®-2C controller ON and OFF. Starting Position: OFF Operational Pressure controls the peak operating pressure of the entire unit. Starting Position: Adjust according to patient population (see below) Inspiratory Flow determines the amplitude delivered to the patient during inspiratory time.
- Page 3 Delivering Therapy Workflow Ensure the patient Set the starting Connect the Gradually increase As patient MASTER Ensure is in an upright, Phasitron to acclimates to SWITCH OPERATIONAL INSPIRATORY is OFF. comfortable the patient therapy, adjust Then, connect the FLOW by turning PRESSURE position, or is lying using mouthpiece,...
- Page 4 NOTE: Display numbers are is represented by the for reference only. Product 24/7 Clinical Support: pulsating peaks of the Bar support 800-850-7250 #2 Graph display. Technical Support: 877-425-8746 Percussionaire PAC-SAL-LIT-733 (1) 130 McGhee Road, Suite 109 service.us@sentec.com 2024-01 Sandpoint, ID 83864...
