- Page 1 Thank you for purchasing an emporia product! Please read this user guide before attempting to use your phone. TALKglam Eveline Pupeter, emporia Telecom www.emporia.eu English...
- Page 2 › YOUR MOBILE PHONE AT A GLANCE Loudspeaker Speed-dial keys Display (screen) (voicemail) Green key Handset volume control • Start or accept a call buttons • In the menu: Port for a charging cable or Confirm selection USB headset • On standby: Access Chats Emergency button Arrow keys (optional)
- Page 3 Symbols on the screen Symbols on the › › external display Network signal Battery LED strength Roaming (abroad) • Slow flashing: Battery is Mobile data enabled charging Battery indicator • On constantly: Battery is fully charged Missed call • Rapid flashing: Battery is out Call forwarding of charge New text message...
-
Page 4: Setting Up Your Phone
1. SETTING UP YOUR PHONE 1.1 Inserting a SIM card and a Micro SD card (optional) 1. Remove the battery cover (opening in the bottom left-hand corner). 2. Slide the SIM card into the SIM card holder with the gold contacts facing down. -
Page 5: Charging The Battery
1.3 Charging the battery Before you use the phone for the first time, charge the battery for at least 4 hours. If you don't charge the phone for this period of time, the battery life could be reduced. Never connect the phone to the charger or a PC if a battery has not been inserted. -
Page 6: Turning On The Phone
1.4 Turning on the phone • Press and hold the key for at least 2 seconds until the emporia logo appears. It will take a few seconds for the home screen to be displayed. 1.5 Entering a PIN code Enter the four-digit PIN code for your SIM card when asked to do so and confirm the entry. -
Page 7: Using The Phone
2. USING THE PHONE 2.1 Home screen If your phone is on but not using a function, it will display the home screen. 12:30 You can return to the home screen any time by pressing the red key Sun, 21.04 several times. Call Info 2.2 Menu key will display the menu. -
Page 8: Dual-Function Keys
2.3 Dual-function keys key: Allows you to listen to your Pressing and holding the voicemail key: Turns on Silent/Sleep mode Pressing and holding the key twice: + for a country code, Pressing the such as +49 for Germany 2.4 Writing text You enter text using the keypad. - Page 9 3. CALLS 3.1 Accepting, declining or ending a call To answer: • Open the phone and for Accept. press the green key To decline or end a call: • Press the red button close the phone. • To mute the ringtone temporarily, press the volume control button.
-
Page 10: Messages (Sms)
4. MESSAGES (SMS) Write message, Received, Unsent, Sent, Menu items: › Delete messages, Text templates, Send contact via SMS, SMS's in Contacts, SMS settings 4.1 Writing and sending a message 1. Open Menu _ Messages. 2. Select Write message. 3. Enter the text using the keypad. 4. -
Page 11: Viewing Photos
5. PHOTO ALBUM AND CAMERA 5.1 Taking photos and recording videos 1. Open Menu _ Tools _ Camera. 2. To Zoom in or out on the camera frame, use the volume buttons on the side of the phone. will open Options for the camera: 3. - Page 12 will be displayed. You can use the arrow keys to move to other photos. • Send: This option allows you to send the selected photo to a recipient as an MMS message. (Please not that this will incur additional costs.) •...
-
Page 13: Alarm Clock
6. TOOLS items: Alarm clock, Calendar, Calculator, Camera, Menu › Bluetooth and SIM Services 6.1 Alarm clock 1. Open Set time. 2. Enter your desired Alarm time and then Save it. 3. The alarm clock is activated and will now go off at the time you have set every day. - Page 14 6.3 Calculator • Enter the numerical values using the number keys. • To write the decimal point in decimal numbers, use • Press to select the calculating function. • Pressing will display the result. 6.4 Bluetooth 1. Turn the Bluetooth function On. 2.
-
Page 15: Editing Contact
7. CONTACTS Search for name, Add contact, Edit contact, Menu items: › Delete, Send contact via SMS, Copy contacts, My number, Speed-dial keys, Emergency contacts, Contact settings, SMS's in Contacts 7.1 Searching for a contact in the phone book 1. When on the home screen, press the phone book key open Menu _ Contacts _ Search for name. -
Page 16: Copying Contacts
7.5 Sending contact via SMS 1. Select the contact you want to send. 2. Enter the recipient's Number or Search for their name in your contacts. 3. You'll then send an SMS that the contact receives as text in the format #Name#Number#. 7.6 Copying contacts You can save one or all the contacts on your SIM card in the phone's memory or vice versa. -
Page 17: Contact Settings
7.9 Contact settings • Save entries on SIM or Phone • Memory in use: SIM, Phone or both • Automatically save in Contacts: On or Off • Memory status: Up to 250 contacts can be saved on the SIM card and up to 300 contacts can be saved on the phone. 7.10 SMS's in Contacts If you receive a message that contains text in the format #Name#Number#, the text will be saved in your contacts... - Page 18 8. CALL INFO Missed calls, Dialled calls, Received calls, Menu items: › Call duration and Delete Each list is sorted chronologically and shows the date and time of each call beneath the contact's name or number. Call, Save in Contacts, Edit number before call, Options: Write message, and Delete When on the home screen, you can access your Chats...
- Page 19 9. SETTINGS items: Silent/Sleep mode, Sound and alerts, Menu › Handset volume, Hands-free volume, Display and light, Time and date, Language, Call waiting, Call forwarding, Suppress number, Network selection, Voicemail number, Emergency numbers, Emergency button, Security settings, Contact settings, 0000 to enter settings, Master reset 9.1 Silent/Sleep mode In this mode, incoming calls will only be indicated by a visual...
-
Page 20: Master Reset
• PIN: PIN request on/off and Change PIN • Phone code: On/Off and Change (factory preset code 1234) 9.5 0000 to enter settings Activate this safety mode to prevent changes being made to settings unintentionally. 9.6 Master reset You can restore all the factory settings on your phone (factory preset phone code: 1234). - Page 21 10. EMPORIA EMERGENCY CALL FUNCTION Your phone has an emergency call function that you can tailor to your specific needs. The Emergency button on the back of the device enables you to call people you trust for help quickly in an emergency.
- Page 22 How do I save an emergency contact? › 1. Open ›Emergency call settings‹. 2. Select an empty position. 3. The list of your contacts will open. Tap on a contact you want to be notified in an emergency. 4. Specify whether the contact is a private individual or a help organisation and also whether they should be sent an emergency call message in addition to receiving the call itself.
- Page 23 Important! Emporia does not assume liability for any costs incurred through you calling such an institution by mistake. How do I delete a saved emergency contact? › 5. Open Settings in the menu _ Emergency contacts _ Delete emergency contact. 6. Select an entry, such as Emergency Contact 1, using the arrow keys.
-
Page 24: Guarantee And Service
GUARANTEE AND SERVICE › Manufacturer: emporia telecom GmbH + CoKG Industriezeile 36, 4020 Linz, Austria Importer: Emporia UK and Ireland Limited · Cardinal Point, Park Road, Rickmansworth, Hertfordshire, WD3 1RE, United Kingdom Contact: www.emporiatelecom.co.uk or www.emporiatelecom.ie Brand name: emporia Model: emporiaTALKglam (F88) ›... - Page 25 › Frequencies › Safety information • BT: 2402 MHz - 2480 MHz • Turn off your phone in hospitals Transmitter power: < 0.0035 W and whenever you are near medical • E-GSM 900/GPRS 900/EGPRS 900: equipment. There should always be a TX: 880 - 915MHz;...
- Page 26 › Intended use • The mains adapter serves as a separator • This phone is robust and designed for between the product and your mains mobile use. However, it still needs to be supply. The mains supply must be close protected from moisture (rain, bathroom to the device and easily accessible.
- Page 27 › Disposal › Declaration of conformity (DOC) • Disposing of the packaging emporia telecom GmbH + CoKG The packaging and pack- (Industriezeile 36, 4020 Linz, Austria), aging aids are recyclable hereby declares that the emporiaTALKglam (F88) and should be recycled. • Disposing of the battery...
- Page 28 Druckfehler, Irrtümer und technische Änderungen vorbehalten. Misprints, errors and technical changes excepted. Con riserva di errori di stampa, inesattezze e modifiche tecniche. Toutes erreurs d'impression, erreurs et modifications techniques réservées. Drukfouten, vergissingen en technische wijzigingen voorbehouden. Part no.: F88_BDA-V1_17006-ENG | 202309...
