Xerox 4110 / 4590 Copier Printer
"How Do I?" guide for Operators
Covered:

How to find MAC address of 4110/4590 built-in Controller

•

How to find MAC address of 4110/4590 Fiery Controller

•
How to find MAC address of 4110/4590 DocuSP Controller
•
How to find MAC address of 4110/4590 built-in Controller
To find the Media Access Control (MAC) address of the 4110/4590 do the following:
1. Print the Configuration Sheet / System Setting List
a. Press the [Machine Status] button on the Control Panel. The Machine Status screen will be displayed on
the Touch Screen.
b. Select the [Billing Meter / Print Report] tab.
c. Select the [Print Report / List] button.
d. Select the [Print Mode Settings] button.
e. Select the [Setting List - Common Items] button.
f. Press the [Start] button on the Control Panel to print the list.
2. After printing the system settings sheet find the header Communication Settings (most likely on page 3 of the
Systems Settings list), the MAC address will be under Ethernet Settings.
NOTE: In this instance, MAC refers to Media Access Control, not the Macintosh.
How to find MAC address of 4110/4590 Fiery Controller
To find the MAC Address on the Fiery DFE Controller:
1. Select [START]
2. Select [Run]
3. Type – cmd and then select [OK]
4. In the CMD Window type – ipconfig /all – then press 'enter'
5. Read the MAC Address as the 'physical address' that is just above the customer's ip address.

How to find MAC address of 4110EPS/4590EPS/4595 DocuSP Controller

To find the MAC Address on the DocuSP DFE do the following:
1. Log on as Administrator User
2. Select [Setup] – Pulldown from top middle of screen.
3. Select [Network Configuration]
4. Select the [Connections] Tab at top of screen
5. The MAC Address is displayed
Title
Find the MAC address
Date
May 2007
Page 1 of 1
