Page 2
Auditron Administrator. The Internal Auditron is the standard system on all machines. Xerox Standard Accounting (XSA) The Xerox Standard Accounting is a feature of the machine which automatically tracks copy, print, scan and fax usage for each user. Usage limits can be applied to users to restrict their usage.
Page 3
Xerox Corporation Internal Auditron Setup at the Device 1. Touch the Log In/Out button. 2. Enter your Login ID, then touch the Confirm button. Quick Start Guide WorkCentre 7228/7235/7245 3 of 18...
Page 4
Xerox Corporation 3. Touch the System Settings button. 4. Touch the Login Setup/Auditron Administration button. 4 of 18 WorkCentre 7228/7235/7245 Quick Start Guide...
Page 5
Xerox Corporation 5. Touch the Login Setup/Auditron Mode button. 6. Touch the Local Machine Access button. Quick Start Guide WorkCentre 7228/7235/7245 5 of 18...
Page 6
Xerox Corporation 7. Choose the appropriate Auditron Mode and Mailbox Access options. 8. Touch the Save button. 6 of 18 WorkCentre 7228/7235/7245 Quick Start Guide...
Page 7
Xerox Corporation 9. Touch the Close button. 10. Touch the Exit button. Quick Start Guide WorkCentre 7228/7235/7245 7 of 18...
Page 8
Xerox Corporation Internal Auditron Setup using Internet Services 1. Access the Internet Services screen for your machine. 2. Click on the Properties tab. 8 of 18 WorkCentre 7228/7235/7245 Quick Start Guide...
Page 9
Xerox Corporation 3. Click on the Auditron Administration link. 4. In the Auditron Mode pull-down box, select the Local Machine Access option. Quick Start Guide WorkCentre 7228/7235/7245 9 of 18...
Page 10
Xerox Corporation 5. Select the appropriate Service (Print, Copy, Scan, etc.) and Mailbox options. 6. Click on the Apply button. 7. Enter your User Name and Password into the appropriate fields, then click the OK button. WorkCentre 7228/7235/7245 Quick Start Guide...
Page 11
Xerox Corporation Xerox Standard Accounting Setup at the Device 1. Touch the Log In/Out button. 2. Enter your Login ID, then touch the Confirm button. Quick Start Guide WorkCentre 7228/7235/7245 11 of 18...
Page 12
Xerox Corporation 3. Touch the System Settings button. 4. Touch the Login Setup/Auditron Administration button. 12 of 18 WorkCentre 7228/7235/7245 Quick Start Guide...
Page 13
Quick Start Guide Xerox Corporation 5. Touch the Login Setup/Auditron Mode button. 6. Touch the Xerox Standard Accounting button. WorkCentre 7228/7235/7245 13 of 18...
Page 14
Xerox Corporation 7. Choose the appropriate Auditron Mode and Mailbox Access options. 8. Touch the Save button. 14 of 18 WorkCentre 7228/7235/7245 Quick Start Guide...
Page 15
Xerox Corporation 9. Touch the Close button. 10. Touch the Exit button. Quick Start Guide WorkCentre 7228/7235/7245 15 of 18...
Page 16
Xerox Standard Accounting Setup using Internet Services 16 of 18 Xerox Corporation 1. Access the Internet Services screen for your machine. 2. Click on the Properties tab. WorkCentre 7228/7235/7245 Quick Start Guide...
Page 17
Xerox Corporation 3. Click on the Auditron Administration link. 4. In the Auditron Mode pull-down box, select the Xerox Standard Accounting option. Quick Start Guide WorkCentre 7228/7235/7245 17 of 18...
Page 18
Xerox Corporation 5. Select the appropriate Service (Print, Copy, Scan, etc.) and Mailbox options. 6. Click on the Apply button. 7. Enter your User Name and Password into the appropriate fields, then click the OK button. WorkCentre 7228/7235/7245 Quick Start Guide...
