Tennant 613341 Operator And Parts Manual

11 gallon low pressure carpet cleaner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
11 Gallon
Low Pressure
Carpet Cleaner
Operator and Parts Manual
Model No.:
613341
613342 - PAC
TENNANT COMPANY
Commercial Products
12875 RANSOM STREET
HOLLAND MI 49424 U.S.A.
FAX: 1-800-678-4240
1-616-786-2345
613345
CUSTOMER SERVICE: 1-800-964-9644
Rev. 00 (04-02)
1-616-786-2330
Home
Find... Go To..

Advertisement

Table of Contents
loading

Related Manuals for Tennant 613341

Summary of Contents for Tennant 613341

  • Page 1 11 Gallon Low Pressure Carpet Cleaner Operator and Parts Manual Model No.: 613341 613342 - PAC TENNANT COMPANY Commercial Products 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. FAX: 1-800-678-4240 1-616-786-2345 613345 CUSTOMER SERVICE: 1-800-964-9644 Rev. 00 (04-02) 1-616-786-2330 Home Find... Go To..

  • Page 2: Table Of Contents

    © 2002 Tennant Company Printed in U.S.A. distributor or from any of the manufacturer’s Castex is a registered United States trademark of Tennant Company subsidiaries. This machine will provide excellent service. However, the best results will be obtained at minimum costs if: •...

  • Page 3: Safety Precautions

    OPERATION 4. Before leaving or servicing machine: SAFETY PRECAUTIONS Turn off machine. – – Unplug cord from wall outlet. 5. When servicing machine: This machine is intended for commercial use. It is designed to clean carpet and upholstery in a indoor Unplug cord from wall outlet.

  • Page 4: Safety Labels

    OPERATION SAFETY LABELS The safety labels appear on the machine in the locations indicated. Replace labels if they become damaged or illegible. FOR SAFETY LABEL- Located on rear panel. FOR SAFETY: Read manual before operating machine. FLAMMABLE MATERIALS/ SPILLS LABEL- Located on rear panel.

  • Page 5: Machine Components

    OPERATION MACHINE COMPONENTS 1. Recovery Tank 8. Empty-Out Nozzle 2. Solution Tank 9. Vacuum Hose Connector 3. Recovery Tank Lid 10. Recovery Tank Drain 4. Solution Tank Lid 11. Latches 5. Vacuum Switch 12. Push/Pull Handle 6. Pump Switch 13. Solution Hose Connector 7.

  • Page 6: Machine Operation

    OPERATION ATTENTION: If using powdered cleaning 2. Take carpet cleaning wand in hand and squeeze chemicals, mix prior to adding. valve trigger while moving the tool in short forward and backward strokes over the carpet NOTE: If desired, water alone achieves excellent (Figure 5).

  • Page 7: Draining Tanks

    OPERATION 2. Operate accessory tool as normal (Figure 7). DRAINING SOLUTION TANK NOTE: Before cleaning upholstery, always check 1. Remove empty-out nozzle from its storage cleaning instructions sewn in furniture by bracket (Figure 9) and attach to end of solution manufacturer.

  • Page 8: Machine Maintenance

    OPERATION MONTHLY MAINTENANCE MACHINE MAINTENANCE (Every 80 Hours of Operation) 1. Lubricate wheels with water resistant oil. To keep machine in good working condition, simply 2. Inspect machine for water leaks and loose follow machine’s daily, weekly and monthly hardware. maintenance procedures.

  • Page 9: Trouble Shooting

    OPERATION TROUBLE SHOOTING PROBLEM CAUSE SOLUTION Machine does not operate. Faulty switches or wiring. Contact Service Center. Faulty power cord. Contact Service Center. Building circuit breaker tripped. Reset Breaker. Solution pump does not operate. Faulty switch or wiring. Contact Service Center. Faulty solution pump motor.

  • Page 10: Specifications

    OPERATION SPECIFICATIONS 11 GALLON LOW PRESSURE CARPET CLEANER Model LENGTH 711 mm (28 in) WIDTH 450 mm (17.7 in) HEIGHT 959 mm (37.8 in) WEIGHT 44.5 Kg (98lbs) SOLUTION TANK CAPACITY 41 L (11 gal) RECOVERY TANK CAPACITY 38L (10 gal) SOLUTION PUMP 120 V, 6.8 bar (100psi), 1.0A VACUUM MOTOR...

  • Page 11: Electrical Diagram

    ELECTRICAL DIAGRAM 120 V WIRING DIAGRAM 11 Gallon Low Pressure Carpet Cleaner (04-02) Home Find... Go To..

  • Page 12: Parts List

    PARTS LIST TANK GROUP 11 Gallon Low Pressure Carpet Cleaner (04-02) Home Find... Go To..
  • Page 13 PARTS LIST TANK GROUP PART # DESCRIPTION QTY. PART# DESCRIPTION QTY. 610527 PNL EDGE PROF 100 BLANK 610483 CLAMP HOSE 2" # 24 • 610538 NOZZEL EMPTY OUT MALE 610534 HOSE VAC 1.5" FLEX 31" 610480 BUSHING HOLDER EMPTY-OUT 610530 HOSE BARB ABS 1 1/2 CUT 610462 10-32 X 1 1/2 PHXZINC...
  • Page 14 PARTS LIST BASE GROUP 11 Gallon Low Pressure Carpet Cleaner (04-02) Home Find... Go To..
  • Page 15 PARTS LIST BASE GROUP REF PART # DESCRIPTION QTY. REF PART # DESCRIPTION QTY. 610470 NUT 1/4-20 NYLOK ZINK 610505 Q/C 1/4" PLUG BR SHUT OFF 610471 WASHER 1/4 FLAT CP 610451 6-32 X 1/2 PHXSS • 610579 610514 CLAMP NYLON CABLE 1/4" BLOWER 3STG 120V 5.7 COMP •...
  • Page 16 PARTS LIST PUMP 100 PSI BREAKDOWN REF# PART # DESCRIPTION QTY. • 610550 PUMP SH FL 100 PSI 120V PLG 610767 PUMP HEAD 100 PSI COMP ASM • 610768 SWITCH ASM, 100 PSI SH FL • 610769 CHECK VALVE ASM, 100 PSI SH FL 610770 HEAD, PUMP DIAPHRAGM •...

  • Page 17: Options

    OPTIONS FLOOR TOOL PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 610642 WAND & HOSE KIT LP -P X 610626 VALVE, KNGSTN STD S BND WAND, FLOORTOOL LP -PX 610630 WAND,FLOORTOOL 610710 COMP. 610629 "U"CLAMP,SUPP HOE HNDL EC 610624 GRIP, FLRTOOL 1 1/2 X 6 610623 NUT 5/16-18 NYLOCK, ZINC 610465...
  • Page 18 OPTIONS HAND TOOL REF PART # DESCRIPTION QTY. REF PART # DESCRIPTION QTY. 610298 TOOL, UPHOLSTERY LP-P X 608898 TRIGGER, HAND TOOL 610668 TOOL, HAND LP BRASS JET W/VLV & TRIG 610658 4-40 X 7/8 PHXZINC 608891 TOOL, HAND W/O TRIGGER 610659 NUT, 4-40 HEX ZINC NYLOK 610654 6-32 X 1 PHXZINC 608892 SEAL, SOLUTION HOSE...
