INSTALLATION INSTRUCTIONS
SMAUD01, SMVID01, SMMAG01, SMLIT01, SMCC01, SMVLT01
DESCRIPTION
The Xantech Sensor Module product line provides several sensing solutions for a wide variety of
automation needs. Used in conjunction with Xantech's award winning MRC platform*, source
management and control is easy and reliable. Also, the sensor modules can be used with the
CBCSM1 connecting block to provide a simple interface solution. The CBCSM1 can provide positive
and negative logic through its PULL UP and PULL DOWN connections.
(* MRC44, MRAUDIO4X4, MRC88, MRAUDIO8X8)
The Xantech Sensor Module product line is composed of six complete, easy to install packages.
SMAUD01
Audio Sensor Module
SMVID01
Video Sensor Module
SMMAG01
Magnetic and Current Sensor Module
SMLIT01
LED and Light Sensor Module
SMCC01
Contact Closure Sensor Module
SMVLT01
AC\DC Voltage Sensor Module
Each module comes with double-sided foam tape and mounting screws. Also, built into the sensor is
a convenient LED light that turns 'on' to indicate the sensor is in an 'on' condition.
SPECIFICATIONS
Delay: Adjustable between 0 and 15 seconds.
+12VDC, <50mA.
1/8" (3.5mm) mini-plug, Tip: +12VDC, Ring: Signal, Sleeve: Ground.
Sensor Module Dimensions: 3/4" W x 3 3/4" L x 3/4" H.
Control Cable Length: Approx. 6 feet
Sensor Cable** Length: 6.5' SMAUD01, SMVID01
Sensor Cable** Length: 5.0' SMMAG01, SMLIT01
(** not applicable on the SMCC01, SMVLT01)
This document is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Xantech
Xantech Corporation shall not be liable for operational, technical, or editorial errors/omissions made in this document.
Sensor Modules
Xantech Corporation
13100 Telfair Avenue, 2/F
Sylmar, CA 91342
Installation Instructions, Sensor Modules
© 2006 Xantech Corporation, Document #08905072A
Corporation.
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Xantech SMAUD01
Summary of Contents for Xantech SMAUD01
- Page 1 (** not applicable on the SMCC01, SMVLT01) This document is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Xantech Xantech Corporation shall not be liable for operational, technical, or editorial errors/omissions made in this document.
- Page 2 ADJUSTMENTS Each sensor module has an adjustment for delay (between 0 and 15 seconds). The delay adjustment determines the amount of time the sensor module remains “on” after the stimulus condition stops. For instance, when SMVLT01 no longer sees a voltage that stimulated the sensor to the “on” condition, the delay will determine when the sensor returns to the “off”...
- Page 3 CD player on either the right or left channel audio cable. SMAUD01 is intended for line-level signals only. Do not use with amplifier outputs or speaker volume controls. (1) Plug the 1/8” (3.5mm) mini-plug into the sensing controller (CBCSM1 and MRC platform provides power to the sensor module).
- Page 4 INSTALLATION – SMVID01: Video Sensor Module The SMVID01 sensor module provides status feedback by monitoring the composite video connection. The sensor head is placed in between and input and output video signal. For instance, the sensor head is placed between a video display and a DVD player on the composite video cable. (1) Plug the 1/8”...
- Page 5 INSTALLATION – SMMAG01: Magnetic and Current Sensor Module The SMMAG01 sensor module provides status feedback by monitoring the AC current in power cords of the AC magnetic fields from CRT monitor and motors. For AC current in power cords, the sensor head is placed on the actual power cord.
- Page 6 INSTALLATION – SMLIT01: LED and Light Sensor Module The SMLIT01 sensor module provides status feedback by monitoring the light or LED indicators found on a majority of electronic equipment. The sensor head is placed on top of the light or LED indicator.
- Page 7 INSTALLATION – SMCC01: Contact Closure Sensor Module The SMCC01 sensor module detects dry switch/relay closure. Two wires form a dry switch or relay contacts can be connect to the screw terminals. When a switch or relay provides a ‘short’ between the two wires, the sensor module is ‘on’.
- Page 8 CSM1 Current Sensor Connecting Block Sensor State FEATURES The CBCSM1 allows the Xantech CSM1 Current Sensor to be used as a general purpose current sensor to sense the power state of a component by detecting the difference in current drawn by the component when it is either ON or OFF and to generate a status signal that can be used to control other equipment.
