Configure the Router

The NetVanta may be initially accessed and managed via the DB-9 CONSOLE port located on
the rear panel of the unit. The default Ethernet port parameters allow the NetVanta to be
accessed using a hub and two Ethernet cables (one for the PC and one for the router). The
default Ethernet IP address is 10.10.10.1. Refer to Configure RIP on page 5 to configure the
Telnet session.

Connect to the Router (Console Port Connection)

1. Connect a VT100 terminal (or PC with VT100 emulation software) to the NetVanta
CONSOLE port using a DB-9 (male) to DB-9 (female) straight-through serial cable.
2. Configure the COM port with the following parameters:
Data Rate: 9600
Data Bits: 8
Parity Bits: None
Stop Bits: 1
Flow Control: None
3. Open a VT100 terminal session. (Please refer to the appropriate VT100 terminal software
documentation for detailed instructions.)
4. Press the <Enter> key.
5. Enter enable at the > prompt.
6. Enter the password when prompted. The default password is password.

Set the Enable Command Security Mode Password (Optional)

If desired, you can set the Enable Security mode password to a password of your choosing by
following the steps below.
1. Enter enable to enter the Enable Security level.
2. At the password prompt, type password (all lowercase).
3. Enter config terminal to enter the Global Configuration mode.
4. At the (config)# prompt, enter enable password word (replace the underlined word with a
password of your choosing) to set your own enable password.
The Enable Security mode passwords are case sensitive.
