LOADING AN APPLICATION IMAGE USING XMODEM

Introduction

The NetVanta 3000 Series Routers contains 7MB of flash memory to allow multiple copies of both

configuration files and application images to be maintained locally on the router for future use. In addition,

the NetVanta 3000 Series Routers provide capability to upload and activate application image files from an

external source using XMODEM. This DLP provides the instructions for uploading a stored application

image for use as the startup image. Application images may be obtained from the ADTRAN website at

http://support.adtran.com.

Prerequisite Procedures

Before beginning this procedure, communication to the unit via the console port must be established.

Tools and Materials Required

•

Computer with terminal emulation software that contains XMODEM capability

•

Appropriate cable to connect terminal to the Console port (customer-provided)

To prevent electrical shock, do not install equipment in a wet location or during a

lightning storm.

ADTRAN suggests that a backup of the current configuration and the current application

image be maintained in flash at all times.

Page 1: Tools And Materials Required
LOADING AN APPLICATION IMAGE USING XMODEM Introduction The NetVanta 3000 Series Routers contains 7MB of flash memory to allow multiple copies of both configuration files and application images to be maintained locally on the router for future use. In addition, the NetVanta 3000 Series Routers provide capability to upload and activate application image files from an external source using XMODEM.
Page 2 This may take several minutes. If necessary, refer to the terminal emulation software documentation for help. The NetVanta 3000 Series Routers only support application image loads using files provided by ADTRAN. The NetVanta 3000 Series Routers VT-100 console will be inaccessible during the in-band XMODEM data transfer.
Page 3 NetVanta 3000 Series Routers DLP-002 sessions.) You can cancel the update at any time using the terminal emulation software (refer to the terminal emulation software documentation for more details). Activate the Application Image 1. Enter boot system flash <filename> to select the application image used at power-up.
