QUICK START INSTRUCTIONS

XIS100 & MRC88m Integration

DESCRIPTION

This document describes how to integrate the XIS100 with the MRC88m, using Dragon-Drop
software.
For this example, we are going to connect the XIS100 to the MRC88m as Source Input 1, and are
going to use the COM RS232 port of the MRC88m for communications with the XIS100.

Physical Connections

Connect the RED and WHITE analog stereo connectors and the YELLOW composite video connector
from the XIS100 to the appropriate SOURCE 1 inputs of the MRC88m.
Connect the RS232 port of the XIS100 to the COM port of the MRC88m. This connection requires a
NULL modem. A common cabling setup would be a straight-thru RS232 cable with a NULL modem
adaptor and a gender-changer adaptor. The Xantech MRC44 Expansion cable (part # 05913560)
can be used to replace both the modem adaptor and the gender changer.

Creating a new MRC88m project

1) Start Dragon-Drop.
2) Select the New Project item under the File Menu ("File->New Project").
3) Open the Audio/Video Distribution project type and select "MRC88m".
4) Select the "Blank Project" Option, then click "OK". You should now see the MRC88m basic
keypad.
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MRC88M and is the answer not in the manual?

Questions and answers

Related Manuals for Xantech MRC88M

Summary of Contents for Xantech MRC88M

  • Page 1: Quick Start Instructions

    This document describes how to integrate the XIS100 with the MRC88m, using Dragon-Drop software. For this example, we are going to connect the XIS100 to the MRC88m as Source Input 1, and are going to use the COM RS232 port of the MRC88m for communications with the XIS100.
  • Page 2 1) In the “Source Input” region, click the check box next to the “Connect to Source Input” text. 2) Make sure that “Source 1” is selected in the drop-down box to the right. This let’s the MRC88m know that Source 1 in the system is the XIS100.
  • Page 3 At this point you have successfully told the MRC88m that an XIS100 is connected, and how it is connected. - 3 -...
  • Page 4 Configuring the MRC88m keypad to control the XIS100 The XIS100 is controlled by using the new “Metadata” Internal Commands. These new commands can be used to control the XIS100, the XMusic, and the iPort. There is a table at the end of this document that describes how each Metadata internal command maps to the XIS100 remote button.
  • Page 5 8) Click the “Accept” Button. You have now successfully programmed the“ PAUSE” button in Zone 1 perform the “Up Arrow” function of the XIS100. Continue programming the rest of the MRC88m keypad buttons to the other desired XIS100 functions. - 5 -...
  • Page 6 Configuring Source 1 correctly for the “Auto Configuration” feature of the SPLCD when connected to a MRC88m 1) On the Virtual Keypad, select SRC1. 2) On the right-hand portion of the Dragon window, select the “Properties” tab near the bottom of the window.
  • Page 7 Metadata Menu Top This document is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Xantech Xantech Corporation shall not be liable for operational, technical, or editorial errors/omissions made in this document.
