INSTALLATION INSTRUCTIONS
MRKP2E
Keypad controller
EU and UK Standard
Safety Information
Read Information — All the safety and operating information should be read before the
appliance is operated.
Follow Information — All operating and use information should be followed.
Retain Information — The safety and operating information should be retained for
future reference.
Heed Warnings — All warnings on the appliance and in the operating instructions
should be heeded.
Wall Mounting — Mounting of this appliance should be done only by an authorized
installer.
Non-Use Periods — Appliances that are left unattended and unused for long periods of
time should be de-energized.
Water — Do not use the apparatus near water.
Cleaning — Unplug the controller unit (MX88/MRC88m/MRAUDIO8x8m) from the
power outlet before cleaning the MRKP2E. Use only a dry cloth to clean the apparatus.
Object and Liquid Entry — Never insert objects of any kind through the openings of
these appliances, as they may touch dangerous voltage points or short-circuit parts that
could result in a fire or electric shock. Care should be taken so that objects do not fall
and liquids are not spilled into the appliance through openings in the enclosure.
Servicing — Do not attempt to service these appliances yourself, as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
Damage Requiring Service — These appliances should be serviced by qualified
service personnel when:
A power supply connection or a plug has been damaged or
If liquid has been spilled into the appliance or objects have fallen into the appliance
or
The appliance has been exposed to water or moisture or
The appliance does not appear to operate normally or exhibits a marked change in
performance or
The appliance has been dropped or the enclosure damaged.
Replacement Parts — When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or that have the
same characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards. The Master Control Unit battery should be replaced
only after turning the power off and only by an authorized installer.
1
Advertisement
Related Manuals for Xantech MRKP2E
Summary of Contents for Xantech MRKP2E
- Page 1 Cleaning — Unplug the controller unit (MX88/MRC88m/MRAUDIO8x8m) from the EU and UK Standard power outlet before cleaning the MRKP2E. Use only a dry cloth to clean the apparatus. Object and Liquid Entry — Never insert objects of any kind through the openings of these appliances, as they may touch dangerous voltage points or short-circuit parts that could result in a fire or electric shock.
- Page 2 Caring For the MRKP2E Clean only with a dry soft cloth. It is important to properly care for your MRKP2E Keypad. Follow these guidelines to ensure your device is preserved and protected. • Do not expose the MRKP2E to rain, liquids or moisture for an extended period of time.
- Page 3 It has been designed to take advantage of all major a single room, but it is possible for a zone to spread across multiple rooms features and capabilities of the MX88. The MRKP2E features hard buttons for (kitchen/dining room, master bedroom/master bath) or for multiple zones to be source selection, volume control, mute, and power.
- Page 4 Typically wires must be fished into position through walls, floors and ceilings. Holes must be cut; speakers The MRKP2E boasts full source control capability and a super bright TFT LCD mounted directly in the ceiling or walls with no electrical back- brackets and touch-screen and its current draw is therefore slightly higher than lesser keypads and local source wall plates must be mounted in existing drywall.
- Page 5 Figure 2.3: MRKP2E Keypad layout and Main display Notes: • Tone Control functions of the MRKP2E can be entered by pressing the RJ45 Connector at Next arrow once inside a source control page. Please note that each of Wire Color...
- Page 6 Figure 2.5 on next page, and then snap the Screw-less Trim Plate in place. TO EXPANSION KEYPAD Note: Do not mount the MRKP2E in the same electrical back- box as high voltage devices such as electrical outlets or switches. MRKP2E...
- Page 7 POWER and “X” buttons (see Figure 2.3). The internal IR receiver receives IR commands for the MRKP2E and for the MX88. It will also pass-thru IR remote control commands to audio sources, via an emitter, to each of the sources connected to the MX88.
- Page 8 Use an external Xantech IR Receiver in cases where a hand-held remote Initial Power-up needs to be pointed somewhere other than at the MRKP2E or in cases where Whenever the MX88 or the keypad itself is reset, the MRKP2 will take additional interference requires the use of a different type of IR receiver or IR approximately 1 minute to initialize.
- Page 9 “Please Restart The Keypad”. To exit this mode, press the “RESET” button behind the MRKP2E trim panel with a blunt object (see figure on page 15). The keypad will reboot and display “Please Load Application Files”. Press the “RESET”...
-
Page 10: Troubleshooting
5. Troubleshooting 6. Specifications Symptom Possible Cause Solution MRKP2E basic dimensions and cable lengths Verify wiring pin-out and RJ- 45 crimp. Correct by re- 1. RJ-45 plug crimped UK Trim Plate: 148mm (5-7/8”) wide x 88mm (3- crimping RJ-45 to CAT-5 incorrectly;... - Page 12 Any products returned to Xantech and found to be defective by Xantech within the warranty period will be repaired or replaced, at Xantech’s option, at no charge. Xantech will not be responsible for the actual cost of the installation or removal of the product, nor for any incidental or consequential damages.
