Xantech XIS100 Installation Instructions Manual

Integration dock for ipod
Hide thumbs Also See for XIS100:
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL
XIS100
Integration Dock for iPod®
INSTALLATION INSTRUCTIONS
08905180B
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XIS100 and is the answer not in the manual?

Questions and answers

Related Manuals for Xantech XIS100

Summary of Contents for Xantech XIS100

  • Page 1 MODEL XIS100 Integration Dock for iPod® INSTALLATION INSTRUCTIONS 08905180B - 1 -...

  • Page 2: Key Features

    480p video output iPods to see their video in full native resolution on a plasma, LCD, or other compatible TV screen with component video input. The ‘XIS100' features a unique on- screen menu display and control system and is compatible with the latest iPod video technology.

  • Page 3: Quick Start

    TV screen and use the iPod’s controls to navigate the Video and/or the Photo folders. STEP 3: The ‘settings’ menu page is unique to the XIS100. On this page, the screensaver time out, behavior of indicator light, color scheme, and language can be changed. See “Settings Menu”...

  • Page 4: Basic Connections

    BASIC CONNECTIONS The XIS100 is ready to be used right out of the box. Simply connect a power supply and determine if composite or component video is required. In all cases, the A/V cable must be used to provide left and right audio connections.
  • Page 5 TV and connect both composite and component outputs from your XIS100 to your TV. In this case, please use a pair of RCA Y-adaptors to connect left and right audio from XIS100 to both inputs of your TV. Other connection possibilities to utilize both video outputs without the use of Y-adaptors may be available depending on your TV or AV Receiver that XIS100 is connected to.

  • Page 6: Remote Control

    Menu can go back to the Main Menu. With XIS100 in stand-by, pressing and holding this key for 5 seconds will reset all settings of the XIS100. The TV will display a confirmation screen. Power Press it to power on and off.

  • Page 7: Base Station - Front View

    BASE STATION – FRONT VIEW Dock Well Connects to the iPod connector. Gently slide the iPod unit into the vertical connector and verify it is not tilted. Included with the XIS100 is a Dock Well adaptor for all iPod units. IR Eye Discreetly hidden is a front panel IR eye used to communicate with the XIS100 remote control.
  • Page 8 ‘settings’ menu. Only one video format can be active. Power input using wall adapter power supply. 5VDC Xantech-supplied power supply only. Use of any other AC adaptor may damage the XIS100 and will void your warranty. - 8 -...

  • Page 9: Settings Menu

    SETTINGS MENU NOTE: The XIS100 will retain all its settings until they are changed again. To return the XIS100 to its default settings, place the XIS100 in standby (connected to a power supply, but not turned on). Point the remote towards the XIS100 and press and hold down the “MENU” button on the remote for more than 5 seconds.
  • Page 10 Serial Port Settings: The XIS100 is shipped with ‘RS232’ setting. The serial port can be set to RS232 or RS422. RS232 is standard usage for equipment located in the same room. For long distance, select RS422. Part number RJ45-to-DB9 Adaptor Description...
  • Page 11 You discover such item was not as warranted above and You promptly notify Xantech in writing, Xantech shall repair or replace the items at its option. Xantech may elect which remedy or combination of remedies to provide in its sole discretion.
  • Page 12 A) Remove the two race track shaped bump-ons from the bottom of the docking station to expose two threaded inserts. B) Use M4x0.7 machine screws (not supplied) to secure the XIS100 base unit in place. C) While screw length will be determined by mounting surface thickness, XIS100’s maximum thread depth is 8mm.
