- Page 1 ED 100, ED 250 PROFESSIONAL Mounting instructions WN 058178 45532/13872 – 2019-07...
- Page 2 ED 100, ED 250 Extended Cover for single-leaf door systems PROFESSIONAL Mount the mounting plate as described in the mounting instructions 058175-45532 for the ED 100/250. Hold the mounting plate extension so that it meets the mounting plate and connect both parts with the aid of the enclosed connector and two screws.
- Page 3 ED 100, ED 250 Extended Cover for single-leaf door systems PROFESSIONAL Turn the bracket by 45° and attach it to the extended mounting plate. Realign the bracket as indicated in picture 6. Move the bracket below the screw heads and screw down tight. Slightly screw in the two thread-cutting screws for the bracket in the middle (a few turns will suffice).
- Page 4 ED 100, ED 250 Extended Cover for single-leaf door systems PROFESSIONAL Fix the program switch inside the bracket and connect it. Wind up the remaining cables and fix them with cable ties to the centre bracket. Mount the operator as described in mounting instructions 058175-45532 for ED 100/250.
- Page 5 ED 100, ED 250 Extended Cover for single-leaf door systems PROFESSIONAL Fix DORMA crown. Fix the perforated lateral cover. Fix axle cover.
