Summary of Contents for Eizo PDS0800-HD

  • Page 1 Instructions for Use PDS0800-HD Dual Link DVI splitter Important Please read the safety information and all information delivered with the product carefully to familiarize yourself with safe and effective usage.
  • Page 2: Legal Information

    Use of EIZO products WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech- nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 3: Table Of Contents

    External software interface to the Large Monitor Manager........ 20 8 Technical specifications .................... 21 Electrical data ...................... 21 Input signal for HD output .................. 22 HD output signal ..................... 23 Mechanical design .................... 24 Climatic conditions.................... 24 Safety regulations .................... 25 Electromagnetic compatibility ................. 25 PDS0800-HD Instructions for Use, 09/2019...
  • Page 4 View from the side .................... 26 10 Appendix .........................  27 10.1 Regulatory Compliance Statements (FCC) ............ 27 10.2 Environmental protection .................. 28 10.3 Warranty ......................... 28 10.4 Additional devices.................... 28 10.5 Repairs ........................ 28 10.6 Contact ........................ 28 10.7 Trademarks...................... 29 Index .......................... 30 PDS0800-HD Instructions for Use, 09/2019...
  • Page 5: Introduction

    1.2 Intended use The Splitter PDS0800-HD is to be used to split one incoming signal into two outgoing sig- nals. It can also be used to downscale two incoming signals in Quad HD format to an outgo- ing signal in FHD format.
  • Page 6: Safety Information

    2 Safety information 2.1 General safety instructions Correct and safe operation of EIZO devices assume professional transport, storage, installa- tion, and connection, as well as careful operation and service. The devices may only be used for applications for which they are commonly used.
  • Page 7 Connection in China Only use power cables approved for China. These power cables are identified by the labels "CCC" or "CQC". Observe the country-specific regulations Observe all regulations of the country in which the device is used. PDS0800-HD Instructions for Use, 09/2019...
  • Page 8 If the device does not function or if a fault cannot be eliminated using the Instructions for Use. • If the device has been dropped and/or the housing damaged. • If the device smells of burning or makes peculiar noises. PDS0800-HD Instructions for Use, 09/2019...
  • Page 9: Description

    • Mini DIN to RGB adapter. 3.2 Features The Splitter PDS0800-HD is a Dual Link DVI Splitter with the following features: • Two independent DVI Dual Link inputs are boosted and doubled, so that two monitors or corresponding devices can be connected to a graphics card output.
  • Page 10: Setup And Installation

    This could result in a short circuit when switching on the device, damaging it. • Wait until the condensed water has evaporated, including that inside the device, before you switch it on. This can take several hours. PDS0800-HD Instructions for Use, 09/2019...
  • Page 11: Installation

    The 12 V DC power supply unit is not connected to line power. Procedure 1. Connect the 12 V DC power supply unit to the PDS0800-HD as shown in the following figure. Note: The PDS0800-HD is delivered with a power supply unit. An additional power sup- ply unit can be connected as a redundant power supply, and is available as an acces- sory.
  • Page 12: Connecting

    CAUTION Shielding measures Follow all shielding measures in accordance with local EMC directives. If these guidelines are not observed, device malfunction may result. PDS0800-HD Instructions for Use, 09/2019...
  • Page 13: Device Connectors

    12 V DC power supply unit connector (ODU Medi-Snap 3 Pin) 5.2.1 DVI Dual Link interfaces Signal splitting is the main function of the Splitter PDS0800-HD. The splitter has two DVI-D inputs, "Input A" and "Input B". Each of the incoming single or dual link signals are dupli- cated into two identical output signals, "Main Output A"...
  • Page 14: The Hd Output Connectors

    Connecting 5.2 Device connectors Up to two PDS0800-HD can be connected in series, where "Main Output A" and "Main Out- put B" are connected to inputs "Input A" and "Input B" of the next splitter. The address has to be increased for the second PDS0800-HD. The address is used by the downstream split- ter to switch the DDC connections.
  • Page 15: Connection Procedure

    5.3 Connection procedure 5.3 Connection procedure CAUTION Connection procedure • During the connection procedure, the PDS0800-HD has to be disconnected from the line power when inserting or pulling connectors. • The work described may only be carried out by service personnel. Prerequisite •...
  • Page 16: Configuring

    6.1 Address rotary control Note Ensure that the first Splitter PDS0800-HD used in the video chain has address "0" and the second splitter has address "1". Use the address rotary control to set the address according to the following table.
  • Page 17: Operation

    After configuring the Splitter PDS0800-HD , operation consists of switching the power on and off. If the PDS0800-HD is operated with a Large Monitor Manager (LMM), it can be controlled through the LMM user interface. The LMM0802, LMM0804, and LMM56800 are suitable LMM models.
  • Page 18: Operating With Lmm56800

    The status window of the LMM56800 user interface contains information based on the num- ber of connected PDS0800-HD and monitors. PDS0800-HD not connected, monitor connected If only monitors are connected to the LMM56800, and no PDS0800-HD, then the LMM sta- tus window displays the following information: Status...
  • Page 19: Power Supply Unit Status

    Operation 7.2 Operating with LMM56800 Two PDS0800-HD connected in sequence with six video sources If two PDS0800-HD are connected in sequence and six DVI outputs are used, the following information is displayed in the LMM56800 status window: Status Description Monitor output 1A.0MA: [Device ID] [Vendor "Output 1A.0MA"...
  • Page 20: Status Of Link Connections

    • PDS0800-HD with address "1" link B: 0 For PDS0800-HD devices with link status "0" means that a link connection was established. Link status "1" means no dual link connection was established. This may be because only a single link connection or no link connection was established.
  • Page 21: Technical Specifications

    Technical specifications 8.1 Electrical data 8 Technical specifications 8.1 Electrical data The Splitter PDS0800-HD requires a 12 V DC power supply unit for operation. A second power supply unit can be installed as a redundant power supply. PDS0800-HD Input voltage 12 V DC ± 10 % Input current 3.0 A max.
  • Page 22: Input Signal For Hd Output

    Requirement Value H display 1920 pixels V display 2160 rows Max. pixel frequency 133 MHz Display both input channels in the HD output sig- The maximum offset between both inputs is 512 pixels. PDS0800-HD Instructions for Use, 09/2019...
  • Page 23: Hd Output Signal

    V total 1125 rows V Field Rate 60 Hz V Frame Rate 30 Hz Signal YPrPb Signal Level In accordance with EIA-770.3 (300 mV/700 mV) Video DACs 3 High Quality 10 Bit with 4x Oversampling Chroma Subsampling 4:2:2 PDS0800-HD Instructions for Use, 09/2019...
  • Page 24: Mechanical Design

    700 - 1060 hPa (525 - 795 mm Hg) or up to 3050 m height (10000 ft) During transport and storage (packed) Temperature range -40 °C to +70 °C ambient temperature according to EN 60068-2-1 and EN 60068-2-2 Humidity 10 % - 95 % non-condensing, at 25 °C according to EN 60068-2-38. PDS0800-HD Instructions for Use, 09/2019...
  • Page 25: Safety Regulations

    Surge on power cables IEC 61000-4-5/EN 61000-4-5 Level 2 • Conducted interference IEC 61000-4-6/EN 61000-4-6 Level 2 • Power frequency magnetic fields IEC 61000-4-8/EN 61000-4-8 Level 2 • Voltage drops, brief power interruptions and IEC 61000-4-11/EN 61000-4-11 Level 3 voltage fluctuations FCC Class A PDS0800-HD Instructions for Use, 09/2019...
  • Page 26: Dimensional Drawings

    9.1 Front view 9.2 View from above Note Only one power supply unit is included in the scope of delivery A second power supply unit is available as an option. 9.3 View from the side PDS0800-HD Instructions for Use, 09/2019...
  • Page 27: Appendix

    Appendix 10.1 Regulatory Compliance Statements (FCC) 10 Appendix 10.1 Regulatory Compliance Statements (FCC) Your EIZO product is marked to indicate its compliance class: • Federal Communications Commission (FCC) – USA FCC Class B Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: •...
  • Page 28: Environmental Protection

    Modifications Any modifications made to this device that are not approved by EIZO GmbH, may void the authority granted to the user by the FCC to operate this equipment.
  • Page 29: Trademarks

    10.7 Trademarks 10.7 Trademarks The EIZO Logo is a registered trademark of EIZO Corporation in Japan and other countries. EIZO is a registered trademark of EIZO Corporation in Japan and other countries. RadiForce is a registered trademark of EIZO Corporation in Japan and other countries.
  • Page 30: Index

     28 Disposal  28 General safety instructions  6 Installation  11 Installation location  10  17 Power connector  12 Power supply unit  22 Service personnel  5 Set-up location  10 Shielding measures  12 User  5 Ventilation  10 Warranty  28 PDS0800-HD Instructions for Use, 09/2019...
  • Page 32 Carl-Benz-Straße 3 76761 Rülzheim Germany Instructions for Use, 09/2019 PDS0800-HD 1013482-003 Copyright © 2019 EIZO GmbH. All rights reserved.
