Instructions for Use
PDC0100
Analog DVI converter
Important
Please read the safety information and all information delivered
with the product carefully to familiarize yourself with safe and
effective usage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDC0100 and is the answer not in the manual?

Questions and answers

Related Manuals for Eizo PDC0100

Summary of Contents for Eizo PDC0100

  • Page 1 Instructions for Use PDC0100 Analog DVI converter Important Please read the safety information and all information delivered with the product carefully to familiarize yourself with safe and effective usage.

  • Page 2: Legal Information

    Use of EIZO products WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech- nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Menu "Language" .................... 22 6.10 Menu "Others" ...................... 22 6.11 Servicelevel 2 functions .................. 28 6.12 Exit OSD ......................... 32 6.13 Lock/unlock OSD menu .................. 32 6.14 System settings ...................... 33 6.14.1 Implementing settings ................ 33 6.14.2 Setting the image geometry .............. 33 PDC0100 Instructions for Use, 01/2020...
  • Page 4 13 Appendix .........................  58 13.1 Markings and symbols .................... 58 13.2 China RoHS (Restriction of Hazardous Substances) .......... 59 13.3 Environmental protection .................. 60 13.4 Additional devices.................... 60 13.5 Warranty ......................... 61 13.6 Repairs ........................ 61 13.7 Contact ........................ 61 13.8 Trademarks...................... 61 Index .......................... 62 PDC0100 Instructions for Use, 01/2020...

  • Page 5: Introduction

    1.2 Intended use The Analog DVI Konverter PDC0100 is used to convert analog signals into a digital video signal. The device is designed for individual connection to a graphics card with a mains voltage of 240 V or 110 Volt.

  • Page 6: Safety Information

    2 Safety information 2.1 General safety instructions Correct and safe operation of EIZO devices assume professional transport, storage, installa- tion, and connection, as well as careful operation and service. The devices may only be used for applications for which they are intended.
  • Page 7 Connection in China Only use power cables approved for China. These power cables are identified by the labels "CCC" or "CQC". Observe the country-specific regulations Observe all regulations of the country in which the device is used. PDC0100 Instructions for Use, 01/2020...
  • Page 8 If the device is brought into a room with a higher or rising temperature, condensed water will form in and on the device. Do not switch on the device until the condensed water has evaporated. Other- wise, the device could be damaged. PDC0100 Instructions for Use, 01/2020...
  • Page 9 Note that monitors can fail as a result of aging, and that image properties such as brightness, con- trast,and color value can change. Do not touch the monitor screen Due to mechanical pressure or electrostatic discharges, touching the screen can result in brief distur- bances to the image. PDC0100 Instructions for Use, 01/2020...

  • Page 10: Description

    PDC0100-SP with Safety notes and documentation CD) . Components The following components are included in the scope of delivery: : • 1 Remote Key Pad for PDC0100 • 1 Power supply • 1 Power cable EU • 1 Ppower cable US •...

  • Page 11: Features

    (PAL/NTSC). The RGB and video inputs can be simultaneously connected to different signal sources. Force Mode The Force Mode function is used to adapt the PDC0100 analog DVI converter to special timing settings. Specially for use on a Large Monitor Manager The analog DVI converter is specially designed for use on a Large Monitor Manager from EIZO.

  • Page 12: Setup And Installation

    The unit should not be switched on until all the condensed water has evaporated, including that inside the unit. This may take several hours, depending on the conditions. 4.2 Mounting the monitor M3 press-in nuts are provided on both sides of the PDC0100for installation. PDC0100 Instructions for Use, 01/2020...

  • Page 13: Connecting

    • Externally connected cables can represent a trip hazard. Make sure that all incoming cables are safely routed. • If the device offers strain relief mechanisms for the cables, use them to prevent unin- tended loosening of connected cables. PDC0100 Instructions for Use, 01/2020...

  • Page 14: Connector Locations

    Connecting 5.2 Connector locations 5.2 Connector locations Inputs of the Analog DVI Konverter PDC0100 Output of the PDC0100 and power supply 5.3 Connecting the signal cables Note • The video signals coming from a graphics card are referred to below as RGB signals, and those coming from a camera, DVD player, video recorder etc.

  • Page 15: Connecting The Power Supply

    Only use power cables approved for China. These power cables are identified by the la- bels "CCC" or "CQC". CAUTION Connection in the USA and Canada Molded power plugs must comply with the requirements for "hospital grade attachments" CSA Std. C22.2 No. 21 and UL 498. PDC0100 Instructions for Use, 01/2020...

  • Page 16: Serial Interface

    Personen, die vom Service eingewiesen wurden, geschehen. • Im Beisein der Patienten dürfen Serial Spot Meter und Universal Serial Luminance Me- ter nicht angeschlossen sein. Der PDC0100 hat zwei serielle RS 232-Schnittstellenbuchsen: • Upstream (vorgeschaltet) RJ11-Buchse: Die Buchse befindet sich direkt neben der VGA-Buchse (beschriftet mit "UP").

  • Page 17: Commissioning

    Network • The Analog DVI Konverter PDC0100 must not be connected to a network. • The RJ45 socket on the PDC0100 and the keypad are used exclusively to connect these together using the network cable supplied with the keypad. The operation LED is located directly on the PDC0100. The 4-key keypad is connected to the PDC0100 via a network cable.

  • Page 18: Osd Overview

    6.3 OSD overview 6.3 OSD overview The OSD menu is used to make settings for operation of the monitor with a source. The OSD can also be operated without an input signal to a limited extent. PDC0100 Instructions for Use, 01/2020...

  • Page 19: Main Menu

    User factory setting: "6500 Note: The user color setting can be changed when °K (native)". "User" is selected. This color can be set by the user. Default: 1 (6500°K) PDC0100 Instructions for Use, 01/2020...

  • Page 20: Menu "Position/Zoom" (Only For Analog Signals)

    The picture is displayed to fill the complete screen (1280 x 1024 pixels). Default: Fill all • Fill ratio: The picture is zoomed to the maximum screen area with re- tention of the aspect ratio. • Square: The picture is zoomed to square format. PDC0100 Instructions for Use, 01/2020...

  • Page 21: Menu "Source

    • The auto functions support automatic adjustment of the parameters. The quality of the settings depends on the picture contents and the type of synchronization. • EIZO recommends that an SMPTE test picture is displayed. • All settings can also be optimized manually using the corresponding functions in the OSD menu.

  • Page 22: Menu "Language

    If the vertical lines are still slightly fuzzy, adjust Phase (only for RGB 0 … 255 the "Frequency/Phase" setting. signals) Note: We recommend that a vertical line from the "Pixel On/Off" test pattern is displayed. PDC0100 Instructions for Use, 01/2020...
  • Page 23 Menu "Video/PIP setting" Function Values Description PIP size Activating and deactivating the PIP window and set- ting the PIP window size. Default: Off PDC0100 Instructions for Use, 01/2020...
  • Page 24 Shift the image in the horizontal direction in the PIP window. (only for analog signal) PIP image vertical position Slider Shift the image in the vertical direction in the (only for analog signal) PIP window. PDC0100 Instructions for Use, 01/2020...
  • Page 25 4 on the front Inactive If "Active" is selected, the PIP window can be Default: Inactive opened or closed with the saved settings us- ing button 4 on the front without opening the OSD menu. PDC0100 Instructions for Use, 01/2020...
  • Page 26 This tool only considers the H and V frequencies. Default: 1 An increase in the tab value results in a larger tolerance band being defined. Minor frequency fluctuations within this range will not result in resynchronization ("Auto in progress"). PDC0100 Instructions for Use, 01/2020...
  • Page 27 • Operating hours of the monitor • OSD version • Configuration version • Current timing • Current source • Screen resolution • Frequency of the input signal (line fre- quency and refresh rate) PDC0100 Instructions for Use, 01/2020...

  • Page 28: Servicelevel 2 Functions

    (e.g., the full brightness is also achieved at 700 mV if the video level is limited at this value). Notice: A specific test pattern and timing are pre- requisites! The A/D converters have already been factory-set and need not be readjusted. PDC0100 Instructions for Use, 01/2020...
  • Page 29 (independent of picture, picture program, graphics card and connectors). • All the pixels on the display area are activated (exception: The first column on the left of the panel remains black). Test of columns or line driver. PDC0100 Instructions for Use, 01/2020...
  • Page 30 To configure a network of several monitors Disabled This function is used to interconnect several monitors so that they can all be calibrated using a single com- Default: Disabled puter (connected to the first monitor). See also Serial interface [} 16] PDC0100 Instructions for Use, 01/2020...
  • Page 31 Suitable for step-by-step setting of an unknown tim- ing or for fine adjustment of a timing whose data have been entered using "Blind mode". See also Monitor adjustment - Force Mode [} 35]. PDC0100 Instructions for Use, 01/2020...

  • Page 32: Exit Osd

    The OSD menu is locked. Unlock • Press button "4" once and then button "2" three times (if the OSD is not active). Locking of the OSD menu has been canceled. Delivery state The OSD is unlocked. PDC0100 Instructions for Use, 01/2020...

  • Page 33: System Settings

    As with all monitors, the LCD monitor also has certain limits, e.g. maximum resolution and refresh rate. • The graphics card must be set when using the monitor such that these limits are main- tained. PDC0100 Instructions for Use, 01/2020...
  • Page 34 OSD menu. NOTICE Permanently higher setting for backlight Please note that a permanently higher setting for the backlight results in a more rapid re- duction in the brightness performance toward the end of service life. PDC0100 Instructions for Use, 01/2020...

  • Page 35: Monitor Adjustment - Force Mode

    Field 1 consists of the lines 1 to 262 1/2, and field 2 of the lines 262 1/2 to 525. Only a few lines are displayed at the top and bottom of each field. PDC0100 Instructions for Use, 01/2020...
  • Page 36 Commissioning 6.14 System settings Fig.: Interlaced scanning system Fig.: Non-interlaced scanning system A non-interlaced image is output on the screen in that all horizontal lines are scanned from top to bottom in one scan. PDC0100 Instructions for Use, 01/2020...
  • Page 37 1. Open a test pattern with a clearly defined border (e.g. SMPTE image). 2. Open the "Blind mode" menu: Main menu → Servicelevel 2 → Force Mode → Blind mode. 3. Enter the timing data into the individual input fields using the Menu, Up and Down keys. PDC0100 Instructions for Use, 01/2020...
  • Page 38 Note: For progressive timings with an image refresh rate greater than 60 Hz, only the items "For static pictures" or "Reset" can be selected in line 6 in the "Blind mode" menu. Note: If the "Reset" setting is selected, all learned values are deactivated in the current Force Mode window. PDC0100 Instructions for Use, 01/2020...
  • Page 39 Sequence for setting a timing 1. Determine start values using auto function 2. Optimize scanning frequency 3. Optimize geometry and resolution Step-by-step instructions for setting a timing can be found in the next three sections. PDC0100 Instructions for Use, 01/2020...
  • Page 40 Note: For progressive timings with an image refresh rate greater than 60 Hz, only the items "For static pictures" or "Reset" can be selected in the "Live mode" menu. 4. Execute the "Force" command using key 2. PDC0100 Instructions for Use, 01/2020...
  • Page 41 "lllllll" for the setting. Optimize the signal fre- quency such that no interferences are present in the picture. If the interval between the interferences becomes larger, and these therefore also become fewer, you are moving the slider in the correct direction. PDC0100 Instructions for Use, 01/2020...
  • Page 42 Note: For progressive timings with an image refresh rate greater than 60 Hz, only the items "For static pictures" or "Reset" can be selected in line 6 in the "Live mode" menu. PDC0100 Instructions for Use, 01/2020...
  • Page 43 To adapt the active resolution range to the actual video signal resolution, perform the follow- ing steps: 1. Open a test pattern with a clearly defined border (e.g. SMPTE image). 2. Open the "Live mode" menu: Main menu → Servicelevel 2 → Force Mode → Live mode. PDC0100 Instructions for Use, 01/2020...
  • Page 44 The location in the "Save custom settings" number where the 1 is set depends on the selected "Custom settings number". For example, if you have selected "1" as the "Cus- tom settings number", the 1st position of "Save custom settings" us set to "1". PDC0100 Instructions for Use, 01/2020...
  • Page 45 If the motion image improvement is to be activated, the setting for this must be changed from "Inactive" to "Active" either in the "Servicelevel 2" → "Others" menu or in the "Blind mode" or "Live mode" of the Force Mode menu. PDC0100 Instructions for Use, 01/2020...
  • Page 46 Despite motion image improvement, staircase signals can occur with PIP images of the signal sources "S-Video" and "Composite Video". The staircase signals can occur if a sig- nal source with motion image improvement is active in the main picture. PDC0100 Instructions for Use, 01/2020...

  • Page 47: Operation

    7.2 Switch on the device The device does not have a power switch, and is switched on and off using the power sup- ply unit. If the device is supplied with current, the green operation LED "Power" lights up. PDC0100 Instructions for Use, 01/2020...

  • Page 48: Cleaning

    Cleaning 8.1 Cleaning 8 Cleaning 8.1 Cleaning NOTICE Cleaning and disinfecting • Remove dust from the device using a dry cloth. • Liquid must not penetrate the device PDC0100 Instructions for Use, 01/2020...

  • Page 49: Troubleshooting

    "Auto adjust" the panel Other LED states Monitor status Both LEDs light up No fault; "Power down" was switched on and is active LED green Video signal recognized, no fault PDC0100 Instructions for Use, 01/2020...

  • Page 50: Technical Specifications

    Via 4-pin mini-DIN socket Composite Over 1x BNC socket Composite & S-Video Video level: 0,5 ... 1.4 Vpp Sync level: 0,2 ... 0.3 Vpp Standards PAL (625 Z / 50 Hz) NTSC (525 Z / 60 Hz) PDC0100 Instructions for Use, 01/2020...

  • Page 51: Controls And Connectors

    At front and rear Weight • Analog DVI converter: 850 g • Keypad: 90 g Dimensions (W x H x D) in mm • Analog DVI converter: 220 x 43 x 170 • Keypad: 100 x 24.5 x 43 PDC0100 Instructions for Use, 01/2020...

  • Page 52: Climatic Conditions

    This product has been assigned a CE marking in compliance with the stipulations of EU di- rectives 2014/30/EU, 2014/35/EU, and 2011/65/EU. Safety standards EN 62368, UL 60950 Approval CSA C22.2 No. 60950-1, cMETus mark Protection class Degree of protection II Degree of protection according to DIN 40050 IP20 PDC0100 Instructions for Use, 01/2020...

  • Page 53: Electromagnetic Compatibility

    3 V/m 80 % AM 1 kHz Noise immunity EN 61000-4-6 150 kHz ... 80 MHz 3 V/m 80 % AM 1 kHz Magnetic constant fields EN 61000-4-8 Max. 4000 A/m Magnetic alternating fields EN 61000-4-8 30 A/m PDC0100 Instructions for Use, 01/2020...

  • Page 54: Dimension Drawings

    Dimension drawings 11.1 View from above 11 Dimension drawings All dimensions in mm 11.1 View from above 11.2 Rear view PDC0100 Instructions for Use, 01/2020...

  • Page 55: View From Right

    Dimension drawings 11.3 View from right 11.3 View from right 11.4 View of keypad PDC0100 Instructions for Use, 01/2020...

  • Page 56: Spare Parts / Accessories

    DVI transmission link. Digital graphics connection supports the transmission of high-quality video data. Using the TDL DVI link set from EIZO, this data can be transmitted over a distance of up to 36 m with- out any reduction in quality.

  • Page 57: Cables And Adapters

    Cables and adapters Different cables and adapters allow problem-free integration of our monitors, even in ex- tremely complex systems. Product Order No. DVI-HDMI-Kabel, 5 m 6GF69801HA00 BNC to VGA cable 6GF69801TB04 UMC-201, USB serial converter 6GF69808WG15 PDC0100 Instructions for Use, 01/2020...

  • Page 58: Appendix

    Symbol for date of production for medical products. WEEE marking: Product must be disposed of separately; materials may be re- cycled. Marking according to ACPEIP (China-RoHS). Symbol for "Comply with the instructions for use". Symbol for "Authorized service personnel only". PDC0100 Instructions for Use, 01/2020...

  • Page 59: China Rohs (Restriction Of Hazardous Substances)

    Appendix 13.2 China RoHS (Restriction of Hazardous Substances) 13.2 China RoHS (Restriction of Hazardous Substances) Model: PDC0100 根据SJ/T11364‑2014《电子电气产品有害物质限制使用标识要求》特提供如下有关污染控制 方面的信息。 The following product pollution control information is provided according to SJ/T11364-2014 Marking for the restriction of the use of hazardous substances in electrical and electronic product.

  • Page 60: Environmental Protection

    The device is in compliance with directive 2011/65/EU for limiting the use of specific haz- ardous materials in electric and electronic devices. 13.4 Additional devices Connected devices such as PCs must meet the relevant safety standards. PDC0100 Instructions for Use, 01/2020...

  • Page 61: Warranty

    13.8 Trademarks The EIZO Logo is a registered trademark of EIZO Corporation in Japan and other countries. EIZO is a registered trademark of EIZO Corporation in Japan and other countries. RadiForce is a registered trademark of EIZO Corporation in Japan and other countries.

  • Page 62: Index

     39 Saving  44 Troubleshooting  49 Disposal  60 User  5 Features  11 Fine adjustment  33, 34 Ventilation  12 General safety instructions  6 Warranty  61 Keypad  17 Live mode  40 Motion image improvement  46 OSD menu  18 PDC0100 Instructions for Use, 01/2020...
