  • Page 3 ___________________ Introduction PDC0100 for analog ___________________ Safety notes video signals ___________________ Description ___________________ Application planning Analog DVI converter ___________________ PDC0100 for analog video signals Assembly ___________________ Connecting Instruction Manual ___________________ Commissioning ___________________ Operation ___________________ Service and maintenance ___________________ Troubleshooting ___________________...
  • Page 4 Note the following: WARNING EIZO products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 5: Table Of Contents

    Adjusting the image geometry ..................... 47 7.4.3 Adjusting the brightness and contrast ..................47 7.4.4 Adaptation of display – video source / graphics card..............48 7.4.5 Display adjustment – Force mode....................49 7.4.5.1 Introduction ..........................49 PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 6 Rear view ............................ 80 12.4 View from above ......................... 80 12.5 View of keypad ..........................81 Accessories ............................83 13.1 Analog DVI converter ........................83 13.2 DVI transmission path and cable ....................83 PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 7 Repairs ............................85 Environmental protection ......................85 Accessory devices ........................85 Contact ............................85 Trademarks ..........................86 China RoHS (Restriction of Hazardous Substances) ..............87 List of abbreviations/acronyms ......................89 Index..............................91 PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 8 Table of contents PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 9: Introduction

    Additional documentation Note These instructions are available on the supplied CD-ROM and on the Internet page of EIZO Display Technologies: Medical Monitor Solutions (http://www.eizo.eu) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 10 Introduction 1.2 Additional documentation PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 11: Safety Notes

    Flawless, safe and reliable operation of the equipment assumes that it has been professionally transported, stored, mounted and installed as well as careful operator control and service. The units may only be used for applications for which monitors are normally used. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 12 There must be no contact to a patient when handling the connection cables. Overload Do not connect too many devices to one socket or extension cable since this could result in a fire or electric shock. Observe the information provided by the manufacturer. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 13 Please ensure that all steps are taken to avoid injuries or incorrect diagnoses. Observe all regulations of the country in which the device is used. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 14 Absolutely avoid scratches, shocks etc.  Remove water drops immediately; extended contact with water discolors the surface.  Clean the screen and the housing using only the cleaning agents referred to in the instruction manual. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 15 Connecting the signal cables (Page 23) Connecting the power supply (Page 24) Serial interface (Page 25) Cleaning (Page 69) Safety regulations (Page 76) General connection information (Page 21) Site (Page 17) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 16 Safety notes 2.1 General safety notes PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 17: Description

    DVI cable, VGA cable PDC0100-SP analog DVI converter without power supply unit or keypad Accessories Power supply unit for 1x PDC0100 Order no.: 6GF6010-0BA03-0AA0 SINPRO power supply; model: MPU15A-105, EU power cable Power supply unit for 1-4x PDC0100 Order no.: 6GF6010-0BA03-0AA1...

  • Page 18: Essential Characteristics

    (PAL/NTSC). The RGB and video inputs can be simultaneously connected to different signal sources. Force Mode The Force Mode function is used to adapt the PDC0100 analog DVI converter to special timing settings. Specially for use on the LMM56800 large monitor manager The analog DVI converter is specially designed for use on the LMM56800 large monitor manager from EIZO.

  • Page 19: Application Planning

    The unit should not be switched on until all the condensed water has evaporated, including that inside the unit. This may take several hours, depending on the conditions. See also General safety notes (Page 9) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 20 Application planning 4.1 Site PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 21: Assembly

    Assembly Mounting the display Installation M3 press-in nuts are provided on both sides of the analog DVI converter for installation. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 22 Assembly 5.1 Mounting the display PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 23: Connecting

     The analog DVI converter must not share a power supply with motors or valves (interference!). Note All input signals and voltages must be in accordance with the SELV protection class. See also General safety notes (Page 9) Electromagnetic compatibility (Page 77) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 24: Connector Locations

    Output of the analog DVI converter and power supply Summary of signals and connections See also Connecting the signal cables (Page 23) Connecting the power supply (Page 24) Serial interface (Page 25) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 25: Connecting The Signal Cables

    The analog pins of the DVI plug are not connected internally. 4-pin mini-DIN socket (video input) ● Connect video cable for the sync video input (Y/C signal) to the 4-pole mini-DIN socket. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 26: Connecting The Power Supply

    12 VDC connection. The device does not have an on/off switch. ● Secure the power supply cable to the metal lug using a cable tie. See also General safety notes (Page 9) Connector locations (Page 22) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 27: Serial Interface

    The socket allows serial bus mode for integration of the analog DVI converter into existing systems (bus connections). In addition, users are able to change the display settings through remote access. See also General safety notes (Page 9) Connector locations (Page 22) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 28 Connecting 6.5 Serial interface PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 29: Commissioning

    The operation LED is located directly on the analog DVI converter. The 4-key keypad is connected to the analog DVI converter via a network cable. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 30: Description Of Osd Menu

    The OSD menu is used to make settings for operation of the flat panel display with a source. The OSD can also be operated without an input signal to a limited extent. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 31 Commissioning 7.3 Description of OSD menu See also Exit OSD (Page 40) Servicelevel 2 functions (Page 41) Lock/unlock OSD menu (Page 46) Menu functions (Page 30) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 32: Menu Functions

    The contrast settings are already optimized for digital DVI signals. Manual changes to these values are not recommended, as this can result in an impairment of picture quality (loss of gray scales). PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 33 Shift picture in vertical direction With identical display and graphics card settings, the complete picture to be displayed fills the display area of the monitor with the exact number of pixels. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 34 "Auto functions" are executed. With "Off", the brightness and contrast are not adjusted when the "Auto functions" are executed. Note This function is not available for "Sync on green signals". PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 35 If the vertical lines are still Phase(only for RGB signals) 0 … 255 slightly fuzzy, adjust the "Frequency/Phase" setting. Note We recommend that a vertical line from the "Pixel On/Off" test pattern is displayed. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 36 Filter No. 1 produces the "sharpest" picture, as it does the least filtering. Filter No. 5 filters the most; the greatest danger exists with this filter that details can no longer be recognized. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 37 The brightness settings are already optimized for digital DVI signals. Manual changes to these values are not recommended, as this can result in an impairment of picture quality (loss of gray scales). PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 38 Shift the image in the (only for analog signal) horizontal direction in the PIP window PIP image vertical position Slider Shift the image in the vertical (only for analog signal) direction in the PIP window PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 39 Default: Inactive If "Active" is selected, the PIP window can be opened or closed with the saved settings using button 4 on the front without opening the OSD menu. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 40 H and V frequencies. Default: 1 An increase in the tab value results in a larger tolerance band being defined. Minor frequency fluctuations within this range will not result in resynchronization ("Auto in progress"). PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 41 The A/D converters have already been factory-set and need not be readjusted. Correction of "Fill all" timings Active Enhances the DVI-D signal quality over long distances, Inactive even when standard cable is used PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 42: Exit Osd

    Note: If the OSD menu is exited by changing the timing or switching off the monitor, the changes made are saved. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 43: Servicelevel 2 Functions

    7.3 Description of OSD menu 7.3.4 Servicelevel 2 functions CAUTION Only servicing personnel trained by EIZO GmbH Display Technologies have access to "Servicelevel 2. The "Servicelevel 2" menu can be accessed from the OSD main menu. Key combination for opening "Servicelevel 2"...
  • Page 44 The 5-digit combination indicates which individual memory addresses have been allocated. Example: 10010 ⇒ Addresses 1 and 4 have been allocated. Reset custom settings Execute Clears the content of the five memory locations PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 45 All the pixels on the  display area are activated (exception: The first column on the left of the panel remains black). Test of columns or line driver. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 46 Serial interface The serial interface can be activated or deactivated. If the serial interface is Default: On deactivated ("Off"), it is possible to suppress e.g. the downloading of firmware. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 47 "Blind mode". Note: See the section "Display adjustment - Force Mode" (Page 49) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 48: Lock/Unlock Osd Menu

    7.4.1 Implementing settings The analog DVI converter automatically recognizes many different timings. However, it may be necessary to adjust the detected timing in certain cases. The required operations are explained here. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 49: Adjusting The Image Geometry

    ● Adjust the contrast so that image sections with 95 % and 100 % gray value still visibly contrast. To adapt the luminosity to the ambient lighting, adjust the backlight brightness (caution: factory-set brightness is no longer observed). See also Menu functions (Page 30) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 50: Adaptation Of Display - Video Source / Graphics Card

    OSD menu. See also Menu functions (Page 30) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 51: Display Adjustment - Force Mode

    Force Mode NOTICE "Force Mode" is an engineering tool Force Mode is only used to determine exotic and unknown timings. Using these data, an unknown timing can be implemented in the monitor. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 52: Foreword (A Number Of Useful Points To Facilitate Understanding Of Timing And The Various Types Of Timing)

    Field 1 consists of the lines 1 to 262 1/2, and field 2 of the lines 262 1/2 to 525. Only a few lines are displayed at the top and bottom of each field. Figure 7-2 Interlaced scanning system PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 53 3 - Active Video (resolution vertical) Total horizontal lines 5 – Total number of lines (horizontal) Horizontal blank pixels 4 – Front Porch (horizontal) Vertical blank pixels 4 – Front Porch (vertical) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 54: Name Equivalence For The Force Mode Menu

    Timings whose setting values are unknown can be set step-by-step in Live mode using test patterns. The changes in the test pattern are output live on the display. See "Live mode" (Page 56). Figure 7-6 Live mode menu PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 55: Blind Mode

    "Live mode" should be used to set unknown timing data step-by-step. NOTICE Saving of data always with "Force" The timing data are only entered into memory by the "Force" command, and the image is displayed with the new parameters. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 56 3. Enter the timing data into the individual input fields using the Menu, Up and Down buttons. 4. Select either "For static pictures" or "For motion pictures" in line 6 in the "Blind mode" menu using key 2. 5. Execute "Force" command using key 2. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 57 "Reset" can be selected in line 6 in the "Blind mode" menu. NOTICE If the "Reset" setting is selected, all learned values are deactivated in the current Force Mode window. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 58: Live Mode

    Sequence for setting a timing 1. Determine start values using autofunction 2. Optimize scanning frequency 3. Optimize geometry and resolution Step-by-step instructions for setting a timing can be found in the next three sections. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 59 2. Open the Live mode" menu: Main menu → Servicelevel 2 → Force Mode → Live mode. 3. Select either "For static pictures" or "For motion pictures" in line 6 in the "Live mode" menu using key 2. 4. Execute "Force" command using key 2. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 60 "Reset" can be selected in line 6 in the "Live mode" menu. NOTICE If the "Reset" setting is selected, all learned values are deactivated in the current Force Mode window. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 61 "For static pictures" or "For motion pictures". The current setting is then saved, and the slider set to the center of the control range. Once you have set the signal frequency optimally, you can continue with the description. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 62 For progressive timings with an image refresh rate greater than 60 Hz, only the items "For static pictures" or "Reset" can be selected in line 6 in the "Live mode" menu. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 63 Commissioning 7.4 System settings NOTICE If the "Reset" setting is selected, all learned values are deactivated in the current Force Mode window. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 64 2. Open the Live mode" menu: Main menu → Servicelevel 2 → Force Mode → Live mode. 3. Select either "For static pictures" or "For motion pictures" in line 6 in the "Live mode" menu using key 2. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 65 Once all settings have been carried out in Force Mode, the desired zoom factor can be selected from the "Position/Zoom" menu. Further use of determined values The values determined step-by-step using "Live mode" can now be copied and entered directly in further displays using "Blind mode". PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 66 1. Up to five timings can be saved in "User / Custom settings". Save the timings in the OSD menu "Servicelevel 2 → User / Custom settings". 2. Select memory location using "Custom settings number". PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 67 If a "3" has been selected in "Custom settings number", the third digit of "Save custom settings" is set to "1". Saved timings can be overwritten at any time. Note Up to five timings can be saved in the menu line "Save custom settings". PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 68 Commissioning 7.4 System settings PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 69: Operation

    The analog DVI converter does not have an on/off switch. If the device is connected via the power supply unit, the operation LED on the power supply unit lights up green permanently. See also Troubleshooting (Page 71) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 70 Operation 8.2 Switch on the device PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 71: Service And Maintenance

    Please note with device maintenance, cleaning and disinfecting  Remove dust from the device using a dry cloth. Liquid must not penetrate the device. See also General safety notes (Page 9) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 72 Service and maintenance 9.1 Cleaning PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 73: Troubleshooting

    "Auto adjust" panel Other LED states Display status Both LEDs light up No fault; "Power down" was switched on and is active LED green Video signal recognized, no fault PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 74 Troubleshooting PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 75: Technical Specifications

    Via DVI-I socket (analog pins are used) RGB signal Video level: 0,5 ... 1.0 V  Sync level: TTL-compatible  SoG signal Video level: 0,5 ... 1.0 V  Sync level: 0,2 ... 0.3 V  PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 76 RJ45 socket on analog DVI converter and keypad to connect these together. Optional settings on the analog DVI converter can be made via this socket. Serial interface RS 232 Via RJ 11 socket PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 77: Controls And Connectors

    Keypad: 100 x 24.5 x 43  11.6 Climatic conditions Operation Temperature range 5 °C ... 40 °C ambient temperature Temperature gradient 5°C/h max., no condensation Air pressure 700 ... 1060 hPa PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 78: Mechanical Requirements

    EN 60950, UL 60950 Approval CAN/CSA - C 22.2 No. 950, CSA/us mark Protection class Degree of protection II Degree of protection according to DIN 40050 IP20 Conformity CE in accordance with guideline 2004/108/EC PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 79: Electromagnetic Compatibility

    Noise immunity EN 61000-4-6 150 kHz ... 80 MHz 3 V/m 80 % AM 1 kHz Magnetic constant fields EN 61000-4-8 Max. 4000 A/m Magnetic alternating fields EN 61000-4-8 Max. 10 A/m PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 80 Technical specifications 11.9 Electromagnetic compatibility PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 81: Dimensional Drawings

    Dimensional drawings All dimensions in mm 12.1 Front view 12.2 View from right PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 82: Rear View

    Dimensional drawings 12.3 Rear view 12.3 Rear view 12.4 View from above PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 83: View Of Keypad

    Dimensional drawings 12.5 View of keypad 12.5 View of keypad PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 84 Dimensional drawings 12.5 View of keypad PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 85: Accessories

    DVI transmission path. Digital graphics connection supports the transmission of high-quality video data. Using the TDL DVI cable set from EIZO, this data can be transmitted over a distance of up to 36 m without any reduction in quality.
  • Page 86 Different cables and adapters allow problem-free integration of our displays, even in extremely complex systems. Product Order No. DVI-HDMI cable, 5 m 6GF6980-1HA00 BNC to VGA cable 6GF6980-1TB04 UMC-201, USB serial converter 6GF6980-8WG15 PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 87: A Appendix

    Accessory devices Devices connected to the analog DVI converter (e.g. PC) must also comply with the relevant safety specifications. Contact Support during installation and for technical questions Medical Monitor Solutions (http://www.eizo.com) PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 88: Trademarks

    Appendix A.6 Trademarks Trademarks The EIZO Logo is a registered trademark of EIZO CORPORATION in Japan and other countries. EIZO is a registered trademark of EIZO CORPORATION in Japan and other countries. RadiForce is a registered trademark of EIZO CORPORATION in Japan and other countries.

  • Page 89: China Rohs (Restriction Of Hazardous Substances)

    EFUP shall be done in accordance with the Product Maintenance Procedures. This product must not be disposed of as unsorted municipal waste, and must be collected separately and handled properly after decommissioning. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 90 Applications of hazardous substances in this medical device are required to achieve its intended clinical uses, and/or to  provide better protection to human beings and/or to environment, due to lack of reasonably (economically or technically) available substitutes. 产品中有毒有害物质或元素的名称及含量 Table of hazardous substances’ name and concentration. PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 91: B List Of Abbreviations/Acronyms

    On-screen display Protective Earth SMPTE Society for Motion Picture and Television Engineers SVGA Super Video Graphics Array TN-S mains Terre Neutre–Separé Thin Film Transistor Video Graphics Array VESA Video Electronics Standards Association PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
  • Page 92 List of abbreviations/acronyms Xtended Graphics Array Units of measurement: Cd/m² Candela/m² (photometric measurement for brightness) 3.426 cd/m² PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...

  • Page 93: Index

    Change of environment, 17 Order No. Keypad with cable, 15 PDC0100 analog DVI converter with power supply unit, 15 Power supply unit for 1-4x PDC0100, EU power Digital input cable, 15 Fine adjustment, 47 Power supply unit for 1-4x PDC0100, US power...
  • Page 94 Shielding measures, 21 Sub-D socket, 23 Support During installation and for technical questions, 85 Ventilation, 17 Video input, 74 Video inputs, 16 Mini-DIN and BNC sockets, 23, 24 Warranty conditions, 85 PDC0100 for analog video signals Instruction Manual, 07/2013, 1012298-004...
