Setup Manual IP Decoding Box Software Version 6.0 Important Please read this “Setup Manual”, and “PRECAUTIONS” (separate volume) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For the latest product information including the “Setup Manual”, refer to our web site : www.eizoglobal.com...
Page 2
EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO product specifications are subject to change without notice.
This product may not be covered by warranty for uses other than those described in this manual. The specifications noted in this manual are only applicable when using the AC adapters and signal cables specified by EIZO. Only use optional products manufactured or specified by us with this product.
Cleaning • Periodic cleaning is recommended to keep the product looking new and to prolong its operation lifetime. • Stains on the product can be removed by moistening part of a soft cloth with water or by using our ScreenCleaner and gently wiping. Attention •...
Contents Notice for this product ......... 3 4-5. Checking a Camera Connection with Ping ............... 32 Cleaning ..............4 4-6. Checking for Duplicate IP Addresses ..33 Disclaimer ..............4 4-7. Checking the IP Address of a Computer ... 33 Network Security Request ........
This chapter describes the settings required for displaying camera (network camera) images on the monitor. 1-1. Package Contents Check that all of the following parts are included. If any of these are missing or damaged, contact your dealer or local EIZO representative. • DX0212-IP (this product) • Setup Manual •...
1-2. Controls and Functions Front Names Details 1. Connection terminal for If the remote control receiver unit cannot be used due to the installation remote control receiver location, connect the remote control receiver unit to this terminal. For unit details, refer to “2-10. Preparing the Remote Control” (page 20). Pressing and holding this button for 10 seconds will initialize the following information: 2.
9. HDMI1 / HDMI2 HDMI output connector. Connects to monitors that support HDMI. This terminal emits the beep sound of the product main unit. Connects 10. Stereo mini jack a commercially available stereo mini jack cable. This terminal does not support the audio output of network cameras.
● Network cable Category 5e or higher straight cable ● USB mouse Used to control the live image screen and setting screen. Attention • Only the live image screen can be controlled with the remote control. ● Computer Used to configure this product and cameras. After configuring, it can be removed from the network. The following settings are available only if you are using a computer.
Additional features are available with the purchase of a license. For details on features, refer to the User’s Manual. For details on purchasing a license, contact your dealer or local EIZO representative. 2-2. Setting Cameras To use this product to display camera images, cameras must be set up in advance.
“ONVIF”: H.264 or MJPEG Note • For the latest support status for H.265, refer to the camera compatibility information on the EIZO website. Bit rate Set the value to 8192 kbps or less. (4096 kbps recommended) Resolution / Frame rate Set the resolution and frame rate according to the number of cameras to be simultaneously displayed on the live image screen.
Page 12
Note Camera stream Typically, cameras support multiple streams and can transmit video at different resolutions and frame rates simultaneously. Video recorder Stream 1 Compression format: H.265 Resolution: 1920 x 1080 Monitor Frame rate: 30 Hz Bit rate: 4096 kbps This product Stream 2 Compression format: H.264 Resolution: 1280 x 720...
2-3. Connecting Devices Note • This product supports PoE+. If the network hub supports PoE+, power is supplied from the network hub, so connecting an AC adapter is not required. • If the network hub does not support PoE+, use an AC adapter (sold separately). Please follow the procedure below to make the connection.
Connect the USB mouse to the USB downstream port. Note • Connecting to a device with USB hub function enables operation with multiple USB devices. 2-4. Turn on the Power and Display the Live Image Screen Press the power button ( ) on the front of the product. The power indicator lights up blue and the live image screen is displayed.
2-5. Displaying the Setting Screen The setting screen can be operated using the monitor console (screen displayed on the monitor) or the web console (screen displayed on the browser). To display the setting screen, it is necessary to log in as a user with a user level of “ADMIN”. Note •...
● When Using the Web Console Use a computer connected to the network to perform operations. Note • For information on computer network settings, refer to “4-7. Checking the IP Address of a Computer” (page 33). Launch the browser. Enter the following address to access the site. Address: http://<IP address of this product>/ In the default settings, the IP address is http://192.168.0.150/.
2-6. Setting the Date and Time Setting the correct date and time in the system will prevent problems communicating with cameras. Select “System” > “Date and Time”. Set the current date and time. Time Zone Settings Item Description Range Time Zone Set the time zone.
2-7. Setting the IP Address Select “System” > “Network”. Set the IP address. ● Network Settings Item Description Range IP Setting Method Select the IP address setting method. DHCP/Manual Note • If you have a DHCP server, select “DHCP” and the IP address will be set automatically.
2-9. Registering a Camera Using Auto Discovery Cameras connected to the network can be automatically detected and registered. Attention The following cameras and video encoders must be registered manually (refer to “3-4. Registering a Camera Manually” (page 23)). • Cameras that cannot be discovered automatically - Cameras on different subnets cannot be discovered automatically.
Chapter 3 Other Settings 3-1. Updating software Use the web console to perform operations. For stable operation of the system, it is recommended to use the latest software. It is not possible to revert to an older version. Select “System” > “Maintenance”. The current software version is displayed.
3-3. Save and Load Settings Data to Other Products Use the web console to perform operations. You can save settings data for products that have completed setup and load them to other products on the network. This eliminates the need to set up one unit at a time. Product in which settings data will be copied from Save Settings Data...
Click “Load Settings Data”. 10. Select the settings data file and enter the password you have set. Do not check “Network Settings”. 11. Click “Execute”. The process is performed. 3-4. Registering a Camera Manually The following cameras and video encoders must be registered manually. •...
Page 24
Item Description Range Certificate Validation Select certificate validation during SSL communication. On / Off Attention • If “Certificate Validation” is “On”, the, it is necessary for the root certificate of the camera to be registered in “Root Certificate” under “Certificate”. Protocol Select the protocol for controlling the camera.
Page 25
When “AXIS” is selected Item Description Range Video Stream Select the view area for the stream. Click “Obtain Stream” to get Depends on the a list of view areas from the camera. camera Note • The view area is used to stream a portion of the entire image. For details, refer to the User’s Manual of the camera.
Page 26
When “SRT” is selected This product operates in Caller mode. Set the camera to Listener mode. Item Description Range Latency Set the latency 20 ms to 8000 ms Enter the SRT stream URI (URI starting with rtp://). Alphanumeric characters (up to 1023 characters) Passphrase Sets the passphrase.
Chapter 4 Troubleshooting 4-1. Power Problems Problem Possible cause and remedy 1. The live image screen is not • The power indicator is not turned on displayed - Is the power correctly connected? Connect the AC adapter or network hub that supports PoE+. - Are the power cords of the AC adapter and network hub properly connected? •...
• Make sure you can connect to the camera (refer to “4-5. Checking a Camera Connection with Ping” (page 32)). • Cameras not verified by EIZO may not be compatible with this product. Consider registering cameras with the “DirectUri” protocol.
4-3. Video Problems Problem Possible cause and remedy 1. Error message “E**-**” is • E01-** displayed - Check if the camera streaming settings are correct (refer to “2-2. Setting Cameras” (page 10)). If the problem is not resolved, refer - The camera may not be operating properly due to high load. to “3.
Page 30
Problem Possible cause and remedy • E03-** - Network bandwidth may be overwhelmed or the display capability of this product may have been exceeded. Reduce the resolution and/or bit rate of the camera (refer to “2-2. Setting Cameras” (page 10)). •...
Page 31
Problem Possible cause and remedy 3. Correct image is not displayed • Select “Live Image Screen” > “Other” and turn “Network traffic • Images are distorted condition” to “On”. A circle indicating the communication status • Displayed images are not smooth is displayed in the upper right corner of the image.
4-4. Other Problems Problem Possible cause and remedy 1. Cannot log in • Re-enter the username and password. • Reset the account information using the Reset button and log in as the default setting account (refer to “1-2. Controls and Functions” (page 7)).
4-6. Checking for Duplicate IP Addresses Select “Troubleshooting” > “Network Connection Status”, and click “Current Status”. If the IP address of this product is duplicated with other devices, “Unicast reply from” will be displayed for the number of duplicated units. Set unique IP addresses. Example) Execution Result - If there are no duplicate IP addresses ARPING 192.168.0.150 from 0.0.0.0 eth0...
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class A digital device. - AC Adapter...
Declaration of compliance with India RoHS We, EIZO Corporation, hereby declare and guarantee that this product has been designed and manufactured in compliance with the E-Waste management rule 2016 which prohibit the inclusion of the following substances except for the exemptions listed in schedule II.
Original Purchaser or any third parties other than as provided under this Warranty. EIZO and Distributors will cease to hold or store any parts (excluding design parts) of the Product upon expiration of seven (7) years after the production of the Product is discontinued. In repairing the Product, EIZO and Distributors will use renewal parts which comply with our QC standards.
