Operating Guide Termix VVX-I with complete insulation
Keep the ECL controller in its position while removing the insulation
front completely by pulling at the lower end of the insulation front.
4.1.3 Mounting the display of the energy meter
Mark the position of the fixation points of the bracket for the energy
display and screw the two plugs supplied into the insulation front.
Mount the bracket for the display of the energy meter.
Mount the display/calculator of the energy meter onto the bracket.
Pull the wires from the sensors inside the unit through the
duct/cut-out in the insulation plate.
