Service Manual
Remove Fan
The following operations can be used to disassemble the fan.
Steps
1.
Disconnect the wire connecting to the fan and main board, as shown in the following figure.
2.
Use T10 quincunx screwdriver to remove 4 screws on the middle frame securing the fan, as shown in
the following figure.
3.
Reverse execute the above step to reinstate.
Instruments.uni-trend.com
UT8806E Desktop Digital Multimeter
25 / 29
