- Page 1 Dishwasher User Manual LVS342CQSX...
-
Page 2: Table Of Contents
The information can be found on the rating plate. Warning / Caution-Safety information General information and tips Environmental information VISIT OUR WEBSITE: To get usage advice, brochures, trouble shooter, service and repair information: www.smeg.com/services/customer-service CONTENTS 1. SAFETY INFORMATION...................2 2. SAFETY INSTRUCTIONS.................4 3. INSTALLATION....................6 4. PRODUCT DESCRIPTION................6 5. - Page 3 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 years • and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
-
Page 4: Safety Instructions
If the supply cord is damaged, it must be replaced by the • manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard. WARNING: Knives and other utensils with sharp points • must be loaded in the basket with their points down or placed in a horizontal position. - Page 5 • Ensure that there are no visible water • Please note that self-repair or non- leaks during and after the first use of the professional repair can have safety appliance. consequences and might void the • If the water inlet hose is damaged, guarantee.
-
Page 6: Installation
3. INSTALLATION Valid only for Germany: Before installation, WARNING! refer to the chapter "Rückschlagventil" in the German user manual. Refer to Safety chapters before installation. For detailed installation information, see the installation instruction supplied with the appliance. 4. PRODUCT DESCRIPTION Worktop Detergent dispenser Ceiling spray arm... -
Page 7: Control Panel
5. CONTROL PANEL On/off button Option button Program button Indicators Programme indicators Start button Display Delay button 5.1 Indicators Indicator Description Salt indicator. It is on when the salt container needs refilling. It is always off while the pro‐ gramme operates. Rinse aid indicator. -
Page 8: Programmes
Indicator Description Extreme indicator. Sterilise indicator. 6. PROGRAMMES The order of the programmes in the table may not reflect their sequence on the control panel. Programme Dishwash‐ Degree of Programme phases Options er load soil Crockery, cut‐ Normal, • Prewash •... - Page 9 Programme Dishwash‐ Degree of Programme phases Options er load soil Crockery, cut‐ • Prewash lery, pots, • Dishwashing 50 - 60 °C Auto pans • Intermediate rinse • Final rinse 60 °C • Drying • Dry Assist None Cleaning • Cleaning 70 °C the appli‐...
-
Page 10: Options
Water (l) Energy (kWh) Duration (min) Programme 1)2) 0.014 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. The values for programmes other than ECO are indicative only. 6.2 Information for test institutes To receive the necessary information for conducting performance tests (e.g. -
Page 11: Settings
8. SETTINGS 8.1 Programme selection mode and How to enter user mode user mode Make sure the appliance is in programme When the appliance is in programme selection mode. selection mode, you can set a programme To enter user mode, press and hold and enter user mode. - Page 12 German French de‐ mmol/l mg/l (ppm) Clarke Water soften‐ degrees grees (°fH) degrees er level (°dH) 11 - 14 19 - 25 1.9 - 2.5 185 - 254 13 - 17 4 - 10 7 - 18 0.7 - 1.8 70 - 184 5 - 12 <4...
- Page 13 • The remaining indicators are off. • The display shows the current setting: e.g. = level 5. 2. Press Program repeatedly to change the setting. 3. Press the on/off button to confirm the setting. 8.3 The rinse aid empty notification The rinse aid helps to dry the dishes without streaks and stains.
-
Page 14: Before First Use
9. BEFORE FIRST USE 1. Make sure that the current level of the 5. Remove the salt around the opening of water softener agrees with the the salt container. hardness of the water supply. If not, adjust the level of the water softener. 2. -
Page 15: Daily Use
3. Remove the spilled rinse aid with an absorbent cloth to prevent excessive You can turn the selector of the foam formation. released quantity (B) between position 1 4. Close the lid. Make sure that the release (lowest quantity) and position 4 or 6 button locks into position. -
Page 16: Hints And Tips
Starting a programme with delay Cancelling the delay start while the start countdown operates 1. Set a programme. When you cancel the delay start you have to 2. Press Delay repeatedly until the display set the programme and options again. shows the desired delay time (from 1 to Press simultaneously Delay and Option until 24 hours). - Page 17 • Remove larger residues of food from the Refer to the instructions on the detergent dishes and empty cups and glasses packaging. before putting them inside the appliance. • Always use the correct quantity of rinse • Soak or slightly scour cookware with firmly aid.
-
Page 18: Care And Cleaning
• Make sure that the spray arms can move • The programme is suitable to the type of freely before you start a programme. load and the degree of soil. • The correct quantity of detergent is used. 11.5 Before starting a programme 11.6 Unloading the baskets Before you start the selected programme, make sure that:... - Page 19 5. Make sure that there are no residues of food or soil in or around the edge of the 1. Turn the filter (B) counterclockwise and sump. remove it. 6. Put back in place the flat filter (A). Make sure that it is correctly positioned under the 2 guides.
- Page 20 CAUTION! An incorrect position of the filters can cause bad washing results and damage to the appliance. 12.5 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes. Clogged holes can cause unsatisfactory washing results.
-
Page 21: Troubleshooting
2. Move the upper basket to the lowest level 5. To install the spray arm (C) back, insert to reach the spray arm more easily. the mounting element (B) in the spray 3. To detach the spray arm (C) from the arm and fix it in the delivery tube (A) by delivery tube (A), turn the mounting turning it clockwise. - Page 22 Problem and alarm code Possible cause and solution The appliance does not fill with • Make sure that the water tap is open. water. • Make sure that the pressure of the water supply is not too low. For this information, contact your local water authority. The display shows •...
- Page 23 Problem and alarm code Possible cause and solution Small leak from the appliance • The appliance is not levelled. Loosen or tighten the adjustable feet door. (if applicable). • The appliance door is not centred on the tub. Adjust the rear foot (if applicable).
- Page 24 Problem Possible cause and solution Poor drying results. • Tableware was left for too long inside the closed appliance. Acti‐ vate the function Dry Assist to set the automatic opening of the door and to improve the drying performance. • There is no rinse aid or the dosage of rinse aid is not sufficient.
-
Page 25: Technical Information
Problem Possible cause and solution Limescale deposits on the table‐ • The level of salt is low, check the refill indicator. ware, on the tub and on the inside • The cap of the salt container is loose. "The water softener" of the door. -
Page 26: Environmental Concerns
It is possible to find information related to the rating plate of the appliance. Refer to the performance of the product in the EU EPREL chapter "Product description". database using the link https:// For more detailed information about the eprel.ec.europa.eu and the model name and energy label, visit www.theenergylabel.eu. - Page 28 156821741-A-402023...
