Contents
1.
Product description _____________________________________ 2
2.
Operating instructions __________________________________ 10
3.
Cleaning and maintenance ______________________________ 11
4.
Troubleshooting _______________________________________ 12
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
This manual contains only the basic information required to use the
appliance. The complete manual can be obtained from
www.smeg.com/download-manuals
by entering the product code shown on the plate attached to the inner
right hand edge of the dishwasher door.
The manual can be accessed quickly via the QR code using a device
with a QR reader application.
1
Advertisement
Related Manuals for Smeg LVS344PM
Summary of Contents for Smeg LVS344PM
- Page 1 This manual contains only the basic information required to use the appliance. The complete manual can be obtained from www.smeg.com/download-manuals by entering the product code shown on the plate attached to the inner right hand edge of the dishwasher door.
-
Page 2: Product Description
User instructions TRANSLATION ORIGINAL INSTRUCTIONS 1. Product description Control panel All the dishwasher controls are grouped on the front panel. Programming and option selection are only possible with the door closed. ON/OFF BUTTON AND WARNING LIGHT OPTION SELECTION BUTTONS AND WARNING LIGHTS “CHILD LOCK”... - Page 3 User instructions Rinse aid lack warning indicator Salt lack warning indicator End of cycle signal “Child lock” option warning light 000 Delayed start indicator, wash cycle duration and alarms Program phases warning lights. LIGHTING Pressing the ON/OFF button will start the dishwasher and will lit up the dishwasher pilot light.
- Page 4 User instructions Warning: during the initial phase of the wash program the spray arms cannot be heard in operation because they start turning about 5 minutes after the start. This is the normal wash cycle sequence. END PROGRAM At the end of the program the DISPLAY shows “end”. By pressing one of the program buttons the dishwasher is ready to start a new cycle.
- Page 5 User instructions PROGRAMS TABLE (1 ) CONSUMPTION PROGRAMME, LOAD CROCKERY AND NUMBER & PROGRAM PROGRESS Water Power (kWh) CUTLERY SYMBOL Liters Hot H2O Cold H2O Recommended for rinsing SOAK dishes while waiting for Cold prewash 0,02 0,02 another wash cycle. Wash cycle for delicate items, such as wine Wash at 45°C...
- Page 6 User instructions PROFESSIONAL PROGRAMS (see “professional programs option”) (1) CONSUMPTION PROGRAMME, LOAD CROCKERY AND PROGRAM Water Power (kWh) NUMBER & CUTLERY PROGRESS SYMBOL Cold Liters PRO GLASSES Wash at 50°C Special program for Cold rinse 11,4 0,82 1,32 washing glasses. Rinse at 70°C ULTRA RAPID Very dirty pans and...
- Page 7 User instructions DURATION AND CONSUMPTION Duration for power Duration for power Duration for power 5.45 kW – P3 3.5 kW – P2 2,0 kW – P1 PROGRAMME NUMBER E Hot H Cold H Hot H Cold H Hot H Cold H SYMBOL 60°C 15°C...
- Page 8 User instructions PRO- CRYSTAL 24’ 29’ 29’ 55’ 20’ 24’ ULTRA RAPID 19’ 25’ 25’ 55’ 14’ 19’ 27’ 32’ 32’ 60’ 22’ 27’ FULL EXPRESS 60’ 60’ 60’ 75’ 55’ 60’ 10 PRO- INTENSIVE 45’ 51’ 51’ 80’ 40’ 45’...
- Page 9 User instructions Automatic door opening-Dry Assist It activates automatically when a program that includes the function it is selected (the light comes on). It can be deactivated b pressing the button (the light turns off). The program ends with a drying cycle that consists of a time during which the door is closed, and a time during which the door is slightly open (just waiting, to assist drying).
-
Page 10: Operating Instructions
User instructions 2. Operating instructions After having installed the dishwasher, remove the basket retainers. 2.1 Adding the salt The salt prevents the formation of scale deposits. Unscrew the cap of the salt container. Only for the first time, fill the container with a litre of water. -
Page 11: Cleaning And Maintenance
User instructions 3. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or switch off the omnipolar circuit breaker. CLEANING THE WATER INTAKE FILTER Close the water supply tap, unscrew the end of the water intake hose, remove the filter A and clean it under running water. -
Page 12: Troubleshooting
User instructions 4. Troubleshooting The dishwasher has an autodiagnosis system capable of detecting and indicating a preset series of possible malfunctions. TABLE OF MALFUNCTIONS DETECTED BY THE AUTODIAGNOSIS SYSTEM FAULT DESCRIPTION E 01 Anti-flooding system tripped (where installed). E 02 The system that limits the water level in the dishwasher has been tripped.
