Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
il tuo prodotto tra le
INSTRUCTION MANUAL
G
U
I
D
E
F
O
R
U
G
U
I
D
E
F
O
R
U
migliori offerte di Lavastoviglie
S
I
N
G
T
H
E
D
I
S
H
W
S
I
N
G
T
H
E
D
I
S
H
W
A
S
H
E
R
A
N
D
T
H
E
A
S
H
E
R
A
N
D
T
H
E
Smeg LVS319S
W
A
S
H
I
N
G
P
R
O
G
R
W
A
S
H
I
N
G
P
R
O
G
R
o cerca
A
M
S
A
M
S

Advertisement

loading

Related Manuals for Smeg LVS319S

Summary of Contents for Smeg LVS319S

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg LVS319S o cerca il tuo prodotto tra le migliori offerte di Lavastoviglie INSTRUCTION MANUAL...
  • Page 3 Contents Description of the controls ________________________________ 3 Operating instructions ___________________________________ 13 Cleaning and maintenance _______________________________ 26 Troubleshooting _______________________________________ 30 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need use your dishwasher safely, correctly and in the most satisfactory manner.

  • Page 4: Description Of The Controls

    User instructions 1. Description of the controls Front panel The ON/OFF is on the top edge of the panel, and all the dishwasher’s other controls and monitoring devices are on the central display. Programming and option selection are only possible with the door closed.
  • Page 5 User instructions VERSION WITHOUT OPTIONS ON/OFF BUTTON SELECTION PROGRAMS BUTTON START/PAUSE BUTTON PROGRAMS LIGHTS PHASES/PROGRAM LIGHTS WATER HARDNESS ADJUSTMENT ON INDICATOR LIGHT The light flashes to indicate that the appliance is in “water hardness adjustment” mode. SALT WARNIN LIGHT Illumination of this light denotes a regenerating salt warning level. NO RINSE AID LIGHT...
  • Page 6 User instructions VERSION WITH OPTIONS ON/OFF BUTTON SELECTION PROGRAMS BUTTON START/PAUSE BUTTON PROGRAMS LIGHTS PHASES/PROGRAM LIGHTS + PROGRAM DELAY (if the option is included) WATER HARDNESS ADJUSTMENT ON INDICATOR LIGHT The light flashes to indicate that the appliance is in “water hardness adjustment”...
  • Page 7 User instructions <<OPTIONS (8)>> Depending on the model, this zone may contain one or more of the following options, identified by the relative symbols and described in more detail in the relevant sections of the manual. It is not possible to select any options when the soak program is being used.
  • Page 8 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER CUTLERY PROGRESS MINUTES POWER WATER & SYMBOL KWh (1) LITRES 1 SOAK Pans and dishes awaiting 0,02 Cold prewash completion of the load 2 RAPID Dishes with light dirt, Wash at 38°...
  • Page 9 User instructions NOTES AND REFERENCES Only run the soak program with half loads. Options cannot be used with the soak program. Standard programme under EN 50242. See information sheet provided IEC/DIN reference programme. **** Reference program for laboratories: Detergent: 20g in the dispenser + 10g in the door or tablet.
  • Page 10 User instructions Washing programs The dishwasher is equipped with a control panel, described in chapter "3. Description of the controls", from which it is possible to carry out all the power switch-on, switch-off and programming operations. Before starting a washing program make sure that: •...
  • Page 11 User instructions STARTING THE PROGRAM To start the dishwasher, press the START/PAUSE button (3) for a few seconds, until the light of the first phase of the selected program starts to flash (confirmation beep). As the program runs, the PHASES/PROGRAM lights (5) will indicate the current cycle status.
  • Page 12 User instructions ANNULLING A PROGRAM To annul the program • press the START/PAUSE button (3 ) for a few seconds; the light of the phase in progress remains on and the light of the program in progress flashes (confirmation beep); •...
  • Page 13 User instructions Flexi Tabs Specifically for washing with combination detergents in tablets, which also contain salt and rinse aid (3in1) or other agents such as glass protector, steel rinse aids, etc. (4in1, 5in1…). When this option is selected, salt and rinse aid will not be dispensed even if the relative compartments contain them.
  • Page 14 User instructions HYCLEAN The "HYCLEAN" option prolongs the final hot rinse to ensure a further reduction in the bacteria level. If the temperature in the tank falls during this stage of the program (e.g. because the door is opened or due to a power blackout), the light of the option and the program lights flash to warn that the additional washing phase has not been completed successfully.

  • Page 15: Operating Instructions

    User instructions 2. Operating instructions Once the dishwasher has been correctly installed, prepare for use as follows: • Adjust the water softening system; • Add the regenerating salt; • Add the rinse aid and detergent. Using the water softening system The amount of scale contained in the water (water hardness index) can cause whitish staining on the dry dishes, which...
  • Page 16 User instructions • Do not use table salt as it contains insoluble substances which, over time, may damage the water softening system. • When necessary, refill the regenerating salt container before starting the washing program. In this way, the excess saline solution will be immediately removed by the water;...
  • Page 17 User instructions WATER HARDNESS TABLE WATER HARDNESS SETTING German French degrees (° dH) Degrees (° dF) All lights off 0 - 6 0 - 11 (no salt) One light on 7 - 10 12 - 18 Two lights on 11 - 15 19 - 27 Three lights on 16 - 21...
  • Page 18 User instructions ADDING THE RINSE AID The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door. To add rinse aid: •...
  • Page 19 User instructions ADDING THE DETERGENT To open the detergent dispenser cap, lightly press the button P. Add the detergent and close the cap carefully. During the washing cycle, the dispenser will be opened automatically. • When a program with hot prewash is selected (see program table), extra detergent must be placed in the cavity G/H (depending on models).
  • Page 20 User instructions The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 21 User instructions WARNING! • Make sure that the dishes are securely in place so that they cannot tip over or obstruct the rotation of the spray arms during the washing cycle. • Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the wash pump.
  • Page 22 User instructions Using the baskets The dishwasher has a capacity of 12 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling.
  • Page 23 User instructions LOADING THE LOWER BASKET Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots, pans and their covers must be loaded upside down. When loading soup plates and dessert bowls, be sure to leave a gap between them. Loading examples: EXAMPLES OF LOADING FOR INTENSIVE DIRT If the bottom basket inserts are of the fold-down type,...
  • Page 24 User instructions CUTLERY BASKET The basket has removable top grids into which items of cutlery should be inserted to keep them properly spaced and allow water to pass between them effectively. The top grids and central lid are in the bag of accessories.
  • Page 25 User instructions UPPER BASKET It is recommended to load the upper basket with small- or medium-sized items such as glasses, small plates, tea or coffee cups, shallow bowls and light objects made from heat resistant plastic. If the upper basket is used in the lowermost position, it can also be loaded with serving dishes, provided they are only slightly soiled.
  • Page 26 User instructions Depending on the models, the basket may be equipped with some or all of the following accessories: Supports for cups or long objects (ladles, spoons…), on the left; can be tipped to the vertical position when not in use. Long-stemmed glass holder, on the left;...
  • Page 27 User instructions ADJUSTING THE UPPER BASKET The height of the top basket can be adjusted to allow large dishes or pans to be placed in the bottom basket. The adjustment procedure may be type A or B, depending on the dishwasher model purchased.

  • Page 28: Cleaning And Maintenance

    User instructions 3. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or switch off the all-pole disconnection device. General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces.
  • Page 29 User instructions CLEANING THE FILTER UNIT • It is advisable to periodically inspect the centre filter C and, if necessary, to clean it. To remove the filter, grip the tabs, turn them anticlockwise and lift upwards; • push the centre filter D from the underside to remove it from the micro-filter: •...
  • Page 30 User instructions BEFORE STARTING THE DISHWASHER AFTER PROLONGED DISUSE: • Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. •...
  • Page 31 User instructions If the dishes fail to dry or remain dull, check that: • there is rinse aid inside the special container; • the rinse aid dispenser setting is correct; • the detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open).

  • Page 32: Troubleshooting

    User instructions 4. Troubleshooting The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated. The system is tripped in case of water leaks. Contact the after-sales service.
  • Page 33 User instructions FAULT DESCRIPTION Turbine flow-regulator malfunction The appliance is not able to "measure" the amount of water loaded accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle. If the problem persists, contact the after-sales service.
  • Page 34 User instructions TECHNICAL DATA 597 ÷ 599 mm Width Depth measured flush with the Free standing: 600 mm outer edge of the control panel Semi-integrated: 570 mm Free standing: from 850 mm to 890 mm from 890 mm to 930 mm Height (depending on models) Semi-integrated: from 820 mm to 890 mm from 860 mm to 930 mm...
