Planning Information
Wine Storage Model 315W
A solid panel must not be
installed on a glass door unit, as
this may cause moisture to form
behind the panel.
Dimensions in parentheses are in
millimeters unless otherwise specified.
I N T E G R A T I N G C A B I N E T R Y
Unless you are installing a stainless steel unit, you will
need to provide a door panel frame, where wine will be
seen from the outside. If you order a stainless steel unit,
the Model 315W will be shipped with the panel and
hardware installed and you will merely install the Sub-Zero.
The door frame of the unit has pre-drilled holes for our
optional handle hardware. Refer to Hardware Considera-
tions on page 8 for specifics about installing handle
hardware on this overlay application.
O V E R L A Y P A N E L S
The overlay panel applied to Model 315W should not be
confused with the Built-In overlay panel application. The
overlay panel will consist of only a frame and would be
5 3
either the / " (16) or / " (19) panel you may be using. It is
8 4
affixed directly to the door itself with screws through a
series of pre-drilled holes in the perimeter of the door
itself. You do not need any backer or spacer panel.
The glass door opening of the Model 315W is designed to
be exposed to room air circulation. Decorative overlays on
the glass should be kept to a minimum. Also, rails and
stiles can be increased in size but should not exceed
cabinet manufacturers standard width. They cannot
exceed overall door panel dimensions specified, as they
would interfere with the operation of the door. The back
sides of rails and stiles that will be visible through the
glass door will need to be finished. Also, the inside edges
of the frames must be finished to match the front surface.
