Planning Information
Integrated Model 736TR
F R A M E L E S S C A B I N E T R Y
3
35 / "*
4
PANEL WIDTH
A
3
45 / "
8
(1153)
A
9
13 / "
16
(345)
A
11
16 / "*
16
(424)
4"*
(102)
36"
(914)
TOE KICK
FINISHED OPENING
A) ALL REVEALS ARE 1/8" (3)
Installation of an Integrated 36" (914)
wide tall unit within frameless cabinetry.
*Dimensions may vary.
Dimensions in parentheses are in
millimeters unless otherwise specified.
F R A M E L E S S C A B I N E T R Y A P P L I C A T I O N S
The illustration below shows a hypothetical installation of
an Integrated 36" (914) wide tall unit within frameless
cabinetry. Review the illustration, giving particular attention
to the overall panel specifications. Also refer to the full-
scale illustrations at the end of this section for specifics
on door openings.
IMPORTANT NOTE: Dimensions are based on a
reveal. A reveal of up to
dimensions need to be adjusted accordingly.
(908)
80"*
(2032)
7
79 / "*
8
(2029)
1
34 / "
2
*
(876)
1
/ " (6) is possible, but panel
4
24"
(610)
SIDE VIEW
*DIMENSIONS MAY VARY
1
/ " (3)
8
