I N T E G R AT E D I N S TA L L A T I O N I N S T R U C T I O N S
A N T I - T I P B R AC K E T
To prevent the unit from tipping forward
and provide a stable installation, the unit
must be secured in place with the anti-tip
blocking bracket.
An anti-tip bracket and hardware is provided
with the Integrated unit. The anti-tip bracket
must be installed on a solid base.
If you are installing the unit in a space deeper
than 24", be sure to locate the anti-tip bracket
so that it engages the unit properly. It is impor-
tant that the anti-tip bracket is placed 24" from
the front of the unit without panels, to the the
back of the anti-tip bracket. Refer to illustra-
tions 1 and 2 below and note that for 27" (686)
wide units dimension A is 13
(457) for 36" (914) wide units.
Finished Flooring
Underlayment
Wall Plate
Subflooring

WOOD FLOOR

Illus. 1
I N S TA L L A T I O N
1
/ " (343), and 18"
2
Finished Flooring
Underlayment
Wall Plate
Subflooring
1 1 / "
2
min CONCRETE
( 38 )
FLOOR
Illus. 2
W O O D F L O O R A P P L I C A T I O N S
1
Use the six #12 x 2 / " wood screws and the
2
1
six / " flat washers provided. Drill pilot holes
4
3
/ " (5) diameter maximum, and be sure that
16
the screws penetrate through the flooring
material and into the wall plate a minimum of
3
/ " (19). Be sure that the screws hold tight.
4
Refer to illustration 1 below.
C O N C R E T E F L O O R A P P L I C AT I O N S
3 3
Use the two / " x 3 / " concrete wedge
8 4
1
anchors, two # 12 x 2 / " wood screws and two
2
1
/ " flat washers provided. Be sure that the
4
anchors and screws hold tight. Refer to
illustration 2 below.
IMPORTANT NOTE: In some installations the
subflooring or finished floor may require
angling the wood screws used to fasten the
anti-tip bracket to the back wall. Refer to
illustrations 1 and 2.
Make sure that there are no electrical
wires or plumbing in the area which the
screws could penetrate.
S P E C I F I C A T I O N S
Dimension A
27" (686) Wide Units
36" (914) Wide Units
1
13 / " (343)
2
18" (457)
9
